Home > Manufacturing & Processing Machinery > Machinery for Food, Beverage & Cereal > Fruit & Vegetable Processing Machinery > JK-FD-20N Vacuum Food Freeze Dryer Fruit Apply Berry Freezer Dryer
JK-FD-20N Vacuum Food Freeze Dryer Fruit Apply Berry Freezer Dryer
US$ 61,500 - 61,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
JKI
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JK-FD-10N Vacuum Freeze DryerUS$ 43,000 - 43,000MOQ: 1 Set -
JK-FD-5N Vacuum Freeze DryerUS$ 23,000 - 23,000MOQ: 1 Set
-
JK-FD-1N Vacuum Freeze DryerUS$ 15,300 - 15,300MOQ: 1 Set
-
JK-FD-0.5N Vacuum Freeze DryerUS$ 12,300 - 12,300MOQ: 1 Set
-
JK-FD-0.5N Hot Sale Vacuum Freeze Dryer/lyophlizer Pilot PlantUS$ 12,300 - 12,300MOQ: 1 Piece
Condition
New
Place of Origin
Shanghai, China
Brand Name
JKI
Model Number
JK-FD-20N
Type
Dehydrator
Voltage
220/380V
Power(W)
22.5KW
Weight
300kg
Dimension(L*W*H)
1560*450*1340mm
Certification
CE ISO
Warranty
1 Year
After-sales Service Provided
Overseas third-party support available
JK-FD Series Vacuum Freeze Dryer
Medium vacuum freeze-drying machine, automatic freeze dryers, production freeze dryers, freeze-drying equipment
Specializing in the production of fruits and vegetables food vacuum freeze dryer lyophilizer automatic, custom
Integrated electric heating heating tray freeze dryer, automatic pharmaceutical lyophilizer fruits and vegetables. Pilot vacuum freeze dryer lyophilizer automatic large-scale production, custom. Production of vacuum freeze-drying machine automatic pharmaceutical freeze dryer lyophilizer fruit.
| Model | JK-FD-0.5N | JK-FD-1N | JK-FD-5N | JK-FD-10N | JK-FD-20N | JK-FD-50N | JK-FD-100N | JK-FD-200N |
| Drying area | 0.5 sq.m. | 1 sq.m. | 5 sq.m. | 10 sq.m. | 20 sq.m. | 50 sq.m. | 100 sq.m. | 200 sq.m. |
| Capacity of Original Material | 5KG | 10KG | 50KG | 100KG | 200KG | 500KG | 1000KG | 2000KG |
| Tray Size mm | 400/300 | 500/400/ | 800/650 | 1000/1000 | 1000/1000 | 1000/1000 | 1000/1000 | 1000/1000 |
| Type of Tray | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate |
| Quantity of Tray | 4 pieces | 5 pieces | 10 pieces | 10 pieces | 20 pieces | 50 pieces | 100 pieces | 200 pieces |
| Working Method | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried |
| Material of Container | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel |
| Control Method | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording |
| Vacuum Pump | Two-stage rotary vane vacuum pump | Two-stage rotary vane vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | Rotary vane vacuum pump + Roche vacuum pump |
| Working Vacuum Degree | =<130pa | =<130pa | =<130pa | =<130pa | =<130pa | =<130pa | =<130pa | =<130pa |
| Ultimate Vacuum | <10pa | <10pa | <10pa | <10pa | <10pa | <10pa | <10pa | <10pa |
| Compressor | Imported compressor | Imported compressor | Imported compressor | Imported compressor | Imported compressor | Imported compressor | Imported compressor | Imported compressor |
| Trays Temperature | -40~60℃ | -40~60℃ | -40~60℃ | -40~60℃ | -40~60℃ | -40~60℃ | -40~60℃ | -40~60℃ |
| Heating Method of Trays | Ceramic Heater | Ceramic Heater | Ceramic Heater | Ceramic Heater | Ceramic Heater | Ceramic Heater | Ceramic Heater | Ceramic Heater |
| Water Capture Capacity 12 hours | >= 5KG | >= 10KG | >= 50KG | >= 100KG | >= 200KG | >= 500KG | >= 1000KG | >= 2000KG |
| Defrosting Metod | Electric heating | Electric heating | Electric heating | Electric heating | Electric heating | Electric heating | Electric heating | Electric heating |
| Cold Water Vapor | NO NEED | NO NEED | NO NEED | NO NEED | NO NEED | NO NEED | NO NEED | NO NEED |
| Power | Single or three-phase power | Single or three-phase power | three-phase power | three-phase power | three-phase power | three-phase power | three-phase power | three-phase power |
| Working Temperature | =< 40℃ | =< 40℃ | =< 40℃ | =< 40℃ | =< 40℃ | =< 40℃ | =< 40℃ | =< 40℃ |
| Rated Power | 2.5kw | 3kw | 8kw | 14kw | 22.5kw | 28kw | 38kw | 55kw |
| The General Working Period | 6 hour | 6hour | 6hour | 6hour | 6hour | 6hour | 6hour | 6hour |
| Pirce | 12300USD | 15300USD | 23000USD | 43000USD | 61500USD | 100700USD | 163000USD | 240000USD |
Our Advantage:
1. Top Quality: We have strict quality control system and enjoy good reputation in the market.
2. Excellent Service: We treat clients as friend and aims at building long term business relatiionship.
3. OEM Accepted: We Can print your own logo on the products.
4. Unbeatable Price: We always ensure high price performance to benefit our customers.
5. Timely Delivery: Your order shall be shipped once finished.
