Cryogenic Used Liquid Nitrogen Tank

Cryogenic Used Liquid Nitrogen Tank thumbnail-1
Cryogenic Used Liquid Nitrogen Tank photo-1
US$ 110 - 1,250 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Condition:
New
Capacity:
31.5L
Brand Name:
ilonger
Contact Supplier Request Quote Chat Now
Shenzhen Longer Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Capacity 31.5L
Brand Name ilonger
Model Number used liquid nitrogen tank
Weight 13.1KG
Certification ISO9001, ISO13485
Warranty More than 5 years

Specifications

used liquid nitrogen tank
1.High-strength aluminum alloy structure
2.High Multi-layer thermal isolation design.

 used liquid nitrogen tank



(1)   used liquid nitrogen tank --Main features:



This are of moderate capacity,which are specially designed for transportation with their special side support or bottom support design, suitable for long distance transportation and reliable.It is less static evaporation loss mass of liquid nitrogen and safety usage, especially for air transportation.

Main features of liquid nitrogen dewar :

1.High-strength aluminum alloy structure;

2.Encoding canisters,for easy recognition and convenient accessing of samples;

3.Protecting jacket,preventing collision and protable;

4.Lockable cover(optional),protecting biological samples stored;

5.Carrying cart(optional),for convenient transferring indoors(limit for containers of 30 liters and above;

6.Multi-layer thermal isolation design,more than five-year vacuum quality guarantee.



(2)    used liquid nitrogen tank --Technical parameter: :



Model Unit YDS-30B YDS-30B-80 YDS-35B YDS-35B-80
Capacity L 31.5 31.5 35.5 35.5
Empty Weight kg 13.1 13.7 14 14.3
Neck Diameter mm 50 80 50 80
Outer Diameter mm 446 446 473 473
Height mm 675 680 680 680
Static Evaporation Loss L/d 0.17 0.23 0.17 0.23
Static Hold Time d 191 136 215 154
Canister Outer Diameter mm 38 63 38 63
Canister Height mm 120/276 120/276 120/276 120/276
Numbers of Canisters ea 6 6 6 6
Straw Holding Capacity (single level) 0.5 ml 792 2244 792 2244
0.25 ml 1788 5022 1788 5022
Straw Holding Capacity (double level) 0.5 ml 1284 3624 1284 3624
0.25 ml 2832 8460 2832 8460
Numbers of Canes ea 24 72 24 72
Numbers of Vials ea 120 360 120 360
Optional Locking Cover 1 ea √ √ √ √



(3).Customer Value:



Safe to travel,transport

1.Good high-thick proportion makes GP tanks not so easyto fall down,unlike other manufactures,due to limited tools,with size getting larger tanks getting taller and taller with sane diameters,which makes tanks more likely to fall down and lose bio-speciman,GP'S YDS-12-90 is the ideal AI tanks,which is 2 liters bigger than YDS-10,but quite lower than YDS-10,bigger foothold to keep from falling down,and can fit into trunk.



Ergonomic to handle:

1.L-section buttom bring fit hands well,conducive for handling Other manufacturers neither has it nor in good design to fit in hands.



Good operability:

1.Canisters and racks can be smoothly put in and taken out from tanks,while most manufactures' tanks can neither fit in all of racks nor taken out smoothly.

2.Plastic box within racks are of popular size,can fit in large size ampoule,while most of manufacturers have narrow range compatibility of ampoule.



(4).Sketch of product structure:



cryogenic used liquid nitrogen tank









5) Detail description:



Practical and good looking tanks



cryogenic used liquid nitrogen tank





Inner shell







  • Less welding joints
  • No wrinkles on surface
  • No scratch on surface
  • Clean Surface



cryogenic used liquid nitrogen tank    cryogenic used liquid nitrogen tank





(6) Standard: ISO9001, ISO13485







We are the only enterprise that acquires the authentication of ISO 9001 and ISO13485 International Quality Management System in the same industry.



cryogenic used liquid nitrogen tank   cryogenic used liquid nitrogen tank
