Outboard Engine T9.9BMS ( Two Stroke,Back Control. Manual Start,9.9HP,short Shaft)

US$ 800 - 820 MOQ: 5 Sets

Key Specifications

Condition:

New

Engine:

2 Stroke

Fuel Type:

Gasoline

Yancheng Charles Electrical-Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port of China(SHANGHAI PORT)

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Engine 2 Stroke

Fuel Type Gasoline

Cylinders 2

Engine Position Outboard

Dimensions (L x W x H) (mm) 56*50(2.20*1.97)

Phelps Outboard Motor, T9.9BMS Features: 1).Manual start, 9.9HP 2).Two stroke, short shaft 3).CE approval

Specification

Model	Unit	T9.9BML	T9.9BMS
Overall length	mm(in.)	680(26.8)
Overall Width	mm(in.)	390(15.4)
Overall Height	mm(in.)	1280(50.4)	1150(45.3)
Transom Height	mm(in.)	567(22.3)	444(17.3)
Weight	Kg	40	38.5
Full throttle Operating Range	r/min	4500~5500
Maximun Output	Kw(hp)@r/min	7.3(9.9)@5000
Idling Speed(neutral)	r/min	700~800
Engine Type		2-STROKE
Cylinders		L2
Displacement	cm3	246
Bore*Stroke	mm(in.)	5650(2.201.97)
Ignition System		CDI
Control System		Tiller Control
Starting System		Manual Start
Gear Positions		Forward-Neutral-Reverse
Gear Ratio		2.08(27/13)
Trim and tilt system		Manual tilt
Fuel tank Capacity	L	24
Engine oil capacity (without oil filter)		(Fuel:oil ration:50:1)
Gear oil Capacity	cm3	250
Propeller Spec.	In	3-9 1/4"×8"
Packing	LWH	1280680390	1150680390
20GP	PCS	82	102
40HQ	PCS	202	236
Packed with soild foam, good strong carton, pallet for sample order B=BACK CONTROL,M=MANUAL START,S=SHORT SHAFT,L=LONG SHAFT
Our Marine Engine Rang Two stroke: 2.5HP ,4HP, 5HP, 8HP, 9.9HP, 15HP and 40HP motors Four stroke, 2.5HP, 4HP, 5HP, 9.9HP, 15HP
