4-wheeled lateral move irrigation system allocation standard:
Main pipe diameter |
:6-5/8″ |
Cantilever pipe diameter |
5-9/16″ |
Pipe length |
22 feet/one,(6.7m) |
Standard span |
54.5m(8 pipes)and 48m(7pipes ) |
Main pipe Flange thickness |
10mm, Flange and pipe adopt double welded technology. |
Working voltage |
460--380V/50--60HZ |
Power supply mode |
diesel generator and the local power company provide |
Tire type |
14.9 X 24,vacuum irrigation tire |
Motor power |
0.75~1.5 horse power |
Motor speed reducer |
output speed of electric transmission gear box :28--86RPM |
Tire speed reducer |
the drive ratio is 50:1 (American UMC) |
Irrigation intensity |
5-50mm (within the range is adjustable) |
Irrigation uniformity |
≥90% |
Climbing capacity |
≤25% |
Span body tower structure |
“V”model tower |
Sprayer: |
USA Nelson D3000;selective configuration: USA Nelson R3000 |
Irrigation intake pressure |
0.20—0.35mpa |
truss height |
3.25m |
Sprayer spacing |
2.2-4m(the quantity:2-3 sprayer/water pipe |
Main cable |
4*4mm²+6*1.5mm²(resist ultra violet and aging) |
The end |
LED working status instruction light |
Main pipe of water supply |
Adopt ground buried, standard is more than 6 inches. |
Irrigation intake |
2 water inlet in the center of the machine head, quick pipe joint structure |
Yulin Irrigation Equipment Co., Ltd is the leading manufacturer for irrigation equipment in China. We had started to supply the center pivot irrigation systems for world famouse irrigation company of American Lindsay since 2000. We are the OEM rpoduction manufacturer of Lindsay from 2000 to 2008,and also the only one factory was certified by them on teconology,process,quality and understand.We had supplied more than 1000 sets of large scale irrigation for many irrigation companies all over the world.
Yulin will dedicated to the construction and development of Modern Agriculture .We will supply advanced irrigation facilities, efficient installation &training programs for the customers all over the world.We also own one professional after-sale service team to service for you at any time.We hope to set up long business relationship with you in the near future.
Packing&Shipping:We will supply the standard exporting wooden box to load the irrigation accessories,and then put these boxes and the whole irrigation parts into the 40'OT or HQ container,and ready to ship to other countries all over the world throughout the famouse shipping line such as COSCO,ZIM,CMA or the appointed shipping agent of foreigner clients.
Pure quality—Yulin Irrigation—Perfect service:
1.best before—sale design.
2.Careful installation and debugging.
3.Satisfactory after service.
The installation step for irrigation system:
irrigation system parts:
Agriculture irrigation plant by Yulin:
