HOSE REEL IRRIGATION SYSTEM SPECIALITY AND PARAMETER LIST
ITEM |
COMMODITY |
TECHNICAL PARAMETER(WATER TURBINE/HYDRAULIC) |
1 |
Diameter of water pipe |
4”(100MM) |
2 |
Material of water pipe |
HDPE |
3 |
Water flow of spray gun |
20-60m3/h |
4 |
Working pressure |
0.8—1.0mpa/0.2-0.4mpa |
5 |
Motive power |
40horse power |
6 |
Type of rducer |
Double speed/hydraulic drive |
7 |
Lengh of pipe |
390m |
8 |
Speed of irrigation |
0.2--20m/min CVT |
9 |
Drive mode |
Water drive/hydraulic drive motor |
10 |
Height of spraying car |
0.9-1.2m |
11 |
Caliber of sprayer gun |
12--24mm |
12 |
Range of spray gun |
30-45m |
13 |
Irrigation quota |
20--60m3/h |
14 |
Spray gun |
Komet Brand |
15 |
Climbing ability |
≤20 slope |
16 |
Double orientation irrigation function |
have |
17 |
Efficient irrigation length |
427.5m |
18 |
Net irrigation area |
20-300mu |
19 |
Wheel interval distance |
adjustable |
we supply you two kinds of hose reel irrigation, one is for water turbine drive, and left is for hydraulic drive. Please check and advise us which of kind you need.
Yulin Irrigation Equipment Co., Ltd is the leading manufacturer for irrigation equipment in China. We had started to supply the center pivot irrigation systems for world famouse irrigation company of American Lindsay since 2000. We are the OEM rpoduction manufacturer of Lindsay from 2000 to 2008,and also the only one factory was certified by them on teconology,process,quality and understand.We had supplied more than 1000 sets of large scale irrigation for many irrigation companies all over the world.
Yulin will dedicated to the construction and development of Modern Agriculture .We will supply advanced irrigation facilities, efficient installation &training programs for the customers all over the world.We also own one professional after-sale service team to service for you at any time.We hope to set up long business relationship with you in the near future.
Packing&Shipping:We will supply the standard exporting wooden box to load the irrigation accessories,and then put these boxes and the whole irrigation parts into the 40'OT or HQ container,and ready to ship to other countries all over the world throughout the famouse shipping line such as COSCO,ZIM,CMA or the appointed shipping agent of foreigner clients.
The hose reel model for selection:
