Help CenterGalvanized Steel Coiled Barbed Wire ( Direct Factoty )
Related Products
-
Electro Galvanised Zinc Coated Barbed Wire ( Direct Factory )US$ 785.2 - 946.5MOQ: 5 Tons -
Ring Barbed Wire Roller ( Direct Factoty )US$ 785.2 - 846.5MOQ: 5 Tons
-
Wholesale Barb Wire Types ( Direct Factoty )US$ 635.2 - 826.5MOQ: 5 Tons
-
Concertina Barbed Wire Specifications and Installation ( Direct Factory )US$ 785.2 - 946.5MOQ: 5 Tons
-
Concertina Razor Coils(Chinese Manufacture)US$ 769 - 899MOQ: 1 Ton
Specifications
galvanized steel coiled barbed wire1.wire gauge:BWG10-18
2.barb length:1.5-3cm
3.babr space:7.5-15cm
4.25kg/50kg per roll
Galvanized Steel Coiled Barbed Wire
Production of galvanized steel coiled barbed wire
1.Barbed wire specification:
2.Barbed wire Gauge: 16#-12#
3.Barb Wire Gauge: 16#-12#
4.Barbed length:1-3cm
5.Barbed spacing:7.5-15cm
6.Barbed Wire Weight:25kg,50kg
7.Barbed Wire Weaving way: Twist, standard
8.Barbed Wire Surface finished: Electro galvanized,Hot dipped galvanized,PVC coated
9.galvanized Barbed wire Materials: Galvanized steel wire, PVC coated iron wire in blue, green, yellow and other colors.
* Single circle barbed mesh
Single circle thorn mesh does not need cramp, it should be installed with the natural form
* Beline barbed mesh
Beline barbed mesh has many span species to sellect.it not only saves fees but also constructs quickly when reaching effect.
* Fense barbed mesh
Fense barbed mesh is a kind of fencing mesh made by the barbed thorn mesh. The barbed is beautiful and practical.mainly used in fence window military protecting.length and dia can be met according to the requirements of the customer.
Ω Hot dipped Galvanized / PVC/ PE Coated Barbed Wire in IOWA type, with 2 strands, 4 points. Barbs' distance 3-6 inches ( Tolerance +- 1/2" ).
Galvanized Barbed Iron Wire is suitable for industry, agriculture, animal husbandry, dwelling house, plantation or fencing.
Ω Patterns Available for Galvanized Steel Coiled Barbed Wire:
√ Single Twisted Barbed Wire
√ Double Twisted Barbed Wire
√ Traditional Twisted Barbed Wire
Ω Features: Galvanized Steel Coiled Barbed wire offers a great protection against corrosion and oxidation caused by the atmosphere. Its high resistance allows greater spacing between the fencing posts
Specifications of galvanized steel coiled barbed wire
Barbed Wire Specification | ||||
Type |
Wire Gauge (SWG) |
Barb Distance (cm) |
Barb Length (cm) |
|
Electric Galvanized Barbed Wire; Hot-dip zinc plating barbed wire |
10# x 12# |
7.5-15 |
1.5-3 |
|
12# x 12# | ||||
12# x 14# | ||||
14# x 14# | ||||
14# x 16# | ||||
16# x 16# | ||||
16# x 18# | ||||
PVC coated barbed wire; PE barbed wire |
before coating |
after coating |
7.5-15 |
1.5-3 |
1.0mm-3.5mm |
1.4mm-4.0mm |
|||
BWG11#-20# |
BWG8#-17# |
|||
SWG11#-20# |
SWG8#-17# |
|||
|
PVC PE coating thickness: 0.4mm-0.6mm; different colors or length are available at customers request. |
|
||
Galvanized Steel Coiled Barbed Wire Packing
Loading in container of galvanized steel coiled barbed wire
Usage of galvanized steel coiled barbed wire
Galvanized steel coiled Barbed Wire mainly serves in protecting of grass boundary, railway, highway and also widely used in military, jail, industry, agriculture, animal husbandry, dwelling house, plantation for fencing.
We are direct factory of galvanized steel coiled barbed wire!
