Specifications
Rice bites thin chips Machine1. Twin Screw Extruder
2. Raw materials: all kind of grains
Rice bites/rice cracker/ rice thin chips machine
1. Description:
Rice bites machine uses rice powder and corn powder as the main raw materials which are extruded, expanded, and pressed to be the exquisite thin chip, and then punched into round, triangle, hexagon shapes by the punching shaper. After dried and seasoned, the finished crispy thin chip with different tastes comes into being. This process line gets extruding curing, steaming, and shaping together, making the production simplified with low consumption and high automation. The grinded waste chip can be reused, that has reduced the production cost. This process line is the best environment protection equipment.
a. Raw materials: adopts rice etc as ingredients
b. Products: Variety shapes are available round, triangle, hexagon shapes
c. Capacity: 150kg/h, 240kg/h, 500kg/h
d. Flow chart: Mixing system---Extrusion system---- Shaping system----Flavoring system---Packing system
e. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries
f. Machines Materials: All the machines are made by stainless steel
g. Technical Parameters
Model |
Installed power |
Real power |
Output |
Dimension |
SP65 |
111.5kw |
63kw |
100-150kg/h |
26000x1200x2200mm |
SP70 |
145kw |
86kw |
200-240kg/h |
29000x1500x2200mm |
SP85 |
120kw |
127kw |
400-500kg/h |
33000x3500x4300mm |
2. Features of Our Twin Screw Extruder:
a. The screws are made by alloy steel (38CrMoAL) and special craft by nitriding process, The HRC hardness is around 60---62, it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of materials.
b. The extrusion barrel is constructed of carbon steel, is made by #45 steel, stainless steel coating.
c. The gearbox has automatic lubrication function, with extends gear life.
d. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.
e. SIEMENS(CHINA) brands electronic parts used in the controller box, make sure the extrusion process perfect.
f. Main Motor from SIEMENS(CHINA), ensure its powerful extrusion and excellent performance.
3. Various Rice Chips Food Made By Our Twin Screw Extruder
4. Outside package: Standard export wooden case. Inner package: stretch film
5. Our cooperation with overseas customers
At present, Our Company locks in 70% market share in China, and our products have been selling well to Germany, Australia, Ukraine, Malaysia, Indonesia, Syria, Philippine, Thailand, Romania, South America, Middle East, Africa and other countries or regions.
a. Customer visiting our factory
b. Installation & commissioning in customer's factory
c. Reference customer's list
6. About US
We, Jinan Sunpring Machinery & Equipment Co., LTD., is a professional food machinery manufacturer in China. An exceptional engineering team, personal customer service center and high-quality manufacturing capabilities have evolved exponentially since our humble beginnings in 2004, making us one of the preeminent providers of reliable extrusion equipment world-wide. We can guarantee customers superior quality machines up to design requirements and perfect working state. Our technicians can also provide all kinds of relevant technology to make the food production clean, healthy and safe.
Sunpring Company has its own manufacturing plants workshops in China, business scope covering mainly machinery and equipment for corn meal milling system, corn flakes & breakfast cereal system, baby food system, corn puff snacks system, pellets system, artificial rice system, soy nuggets system; as well as pet food/fish food system.
Sunpring Company engages in the technical research of extrusion foodstuff, in order to let our clients have superior foodstuffs to sell in the market. We can improve client's equipment and provide related training on new advanced technique. We can also make special designs for special products and materials according to clients' special requirements.
7. We Provide Satisfied Service & Turnkey Solution
a. We can keep product design in the same level with internationally advanced technology consistently.
b. We have high diathesis staff and excellent processing equipment, and quality control runs through the whole production process from parts stock to the beginning of production.
c. We can guarantee customers superior quality machines up to design requirements and perfect working state.
d. Our technicians can also provide all kinds of relevant technology to make the food production clean, healthy and safe.
e. We will dispatch our technicians to your factory to guide you installation and commissioning work and training your operator.
f. We provide 1 year complete Guarantee and life-time maintenance service.
If you have any needs or enquiries, please feel free to contact me. Thank you very much!
