Home > Products > Palm Fruit Processing Line > palm stripper
palm stripper
- 20 Set / Sets per Month
- Tianjin/Qingdao
- T/T L/C D/P D/A PayPal Credit Card
Product Details
Type: | Cold & Hot Pressing Machine, palm stripper | Use: | Palm Oil | Certification: | ISO9001, BV, CE |
Place of Origin: | Henan, China | Brand Name: | QIE | Model Number: | YZYZ-5 |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Palm stripper
Raw Material:Suitable for palm oil seeds and others
Export markets:Europe, Southeast Asia, Africa, etc
Work principle:Mechanical extruding
Warranty period:One year
English manual:Yes
Factory visiting:Yes
Min.Order Quantity:1 Set/Sets palm stripper
Port:Qingdao, or other ports
Packaging Details:Export wooden case.
Delivery Detail:Within 30 days after your confirmed order.
Quick Details
- Condition: New
- Usage: Palm Oil
- Type: Cold & Hot Pressing Machine, palm stripper
- Automatic Grade: Automatic
- Production Capacity: 1tpd-30tpd
- Place of Origin: Henan, China (Mainland)
- Brand Name: QIE
- Model Number: YZYZ-5
- Voltage: Design according to customer demand
- Power(W): 11 KW
- Dimension(L*W*H): 4935*1523*2664
- Weight: Standard
- Certification: ISO9001, BV, CE
- After-sales Service Provided: Engineers available to service machinery overseas
- Color: Design according to requirement
- Production condition: One to two staff
- Material: Stainless steel or carbon steel
- Raw Material: Suitable for palm oil seeds and others
- Export markets: Europe, Southeast Asia, Africa, etc
- Work principle: Mechanical extruding
- Warranty period: One year
- English manual: Yes
- Factory visiting: Yes
Packaging & Delivery
Packaging Details: | Export wooden case. |
---|---|
Delivery Detail: | Within 30 days after your confirmed order. |
palm stripper
palm stripper
How to get crude palm oil?
Palm oil process line includes sterilizing, threshing, digesting, pressing, clarification, purification
and drying. Then you can get crude palm oil.
Sterilization: Boiling and sterilizing bunches with high temperature( more than 145 C).
Palm fruit bunch are airtight sterilized in sterilizer. The purpose is to prevent enzymes
broken down, avoiding FFA content in oil further increase; easy threshing machinery;
pretreatment peel, prepared for the follow-up processing; pre-conditioning stone, reducing
the damage kernel.
Threshing:Separating fruits from bunches by strong vibration. The purpose of threshing is
to separate oil palm fruit from the fruit bunch through strong vibration, Threshing equipment
is revolving drum thresher. The separated oil palm fruit is ejected then into the pressing section.
Empty fruit bunch be ejected to the yard from the other side of the revolving drum, or shipped out
from the plant as palm orchards slipcover to recycling use, or burning in the locale as fertilizer
for agricultural land.
Digesting:Stiring fruits. Before pressed, oil palm fruit first be carried out cooking, sterilized fruit
must be re-heated to make the pulp soft and damage pulp cell structure.
Pressing: After pressing, oil palm fruit is divided into two parts: oil, water, solid impurities mixture
and the press cake (fiber and nut). Oil, water, solid impurities mixture inflow to oil purification section
by the crude oil gutter; pressed cake into the fiber- recovery section by breaking screw conveyor.
Clarification and purification: Removing oil and sludge (get 90% pure oil), the oil
contains 45%-55% moisture, sludge, and other wastes. Machine-pressed crude oil first diluted
with water washing, the fiber material removed from the oil through settlement and filtration,
and then carry out continuous settlement, the whole divided into two parts: oil
and sediment.
Drying: Through centrifugal separation and vacuum drying, oil is pumped into the storage tank
for storing; oil sediment by filtration and dirt oil separation, oil proceeds second settlement,
dirty oil mixture proceeds clarification separation, skim oil then be carried out a second settlement,
sewage pumps to sewage treatment pond for dealing.
Some datas
Crude palm oil standard:
FFA | less than 5% |
Moisture | less than 0.1% |
Dirt | less than 0.02% |
Kernel standard:
Broken kernel | less than 15% |
Moisture | less than 7% |
Dirt | less than 6% |
Production quality index:
1,transparency : clear and transparent.
2,smell and taste: no strange smell;
3,color (lovibond colorimeter 133.4 slots) R1Y10;
4,moisture and volatile matter: 0.10%;
5,impurities content : 0.10%;
6,acid value (mgKOH/g) : 0.12;
7,peroxide value (mmol/kg): 3.
How to get crude palm kernel oil?
Crude palm kernel oil process line includes polishing, crushing and pressing.
Polishing: Separating nuts and fiber by wind drying system. Pressed cake broken by breaking
screw conveyor and then transported into the fiber separation air net and fiber polishing roller
for fiber separating. The separated fiber material is sent to the boiler room as fuel; the separated
stone is transported to stone warehouse by pneumatic conveying system for temporary storage.
Crushing: Crushing nuts to get kernels and shells. The nut is divided into two or more petal
by corrugated crusher, kernel is released. The broken mixture enters into broken mixture
separation system; separation system adopts two stage separation and water separation.
After separation, shell is sent to the warehouse for temporary storage, as boiler room fuel
when necessary.
Pressing: Pressing kernels to get crude palm kernel oil with machine as below. For more information
of this machine, please check: Full automatic pumpkin seed oil press machine
How to get better oil
If you want to get better quality oil, you can refine and fractionate it.
It includes degumming, bleaching, deodorization, deacidification and fractionation.
For more information, please check: crude palm oil refining line
