Flour White Sugar Fine Powder Stainless Steel Rotary Vibrating Screen

Product Application

High frequency vibrating screens are the most important screening machines primarily utilised in the mineral

processing industry. They are used to separate feeds containing solid and crushed ores down to

approximately 200um in size, and are applicable to both perfectly wetted and dried feed. The frequency of the screen is mainly controlled by an electromagnetic vibrator which is mounted above and directly connected to

the screening surface. Its high frequency characteristics differentiates it from a normal vibrating screen. The

high frequency vibrating screens usually operates at an inclined angle, traditionally varying between 0 to 25

degrees and can go up to a maximum of 45 degrees. Besides, it should operate at a low stroke and has a

frequency ranging from 1500 - 7200 RPM.

Main Features

1. Designed to achieve low power consumption

2. Flexible operation support with no screen chocking/clogging

3. Modular design support with low maintenance requirements

4. Compact finish support

5. Designed to efficiently handle varying feed rates and consistencies

6. Multilevel screen surfaces with accurate separation support in different mesh sizes

7. Suitable for wet or dry separations

8. Adjustable angle of throw

9. Also allows adjustable stroke making

Machine Parts

Name: vibration screen

Original: Hong yuan
