Home > Products > Grain Packing Machine > 25kg-50kg big woven bag rice packing machine
25kg-50kg big woven bag rice packing machine
- 300 Set / Sets per Month
- Qindao tianjin shanghai guangzhou or as per demand
- T/T L/C D/P D/A Credit Card PayPal
- auto bag edge banding rice packing machine
- fertilizer bag edge banding types fertilizer packing machine
- rational weighing scales types fertilizer bagging machine
- 5kg, 10kg, 25kg auto bag stitch rice packaging machine
- auto sewing 25kg bag of rice packaging machine
- big woven bag 25-50 kg granules sugar bagging machine
Product Details
Condition: | New | Application: | Other, any kinds of granules and powder, 50kgs urea fertilizer bagging machine | Packaging Type: | Bags |
Packaging Material: | Other, fertilizer, granules, powder | Automatic Grade: | Semi-Automatic | Driven Type: | Electric |
Voltage: | 220V/380V | Power: | 2.2KW | Brand Name: | hongyuan |
Model Number: | DCS-50 | Weight: | 500KG | Dimension(L*W*H): | 3000*1300*3300 |
Certification: | CE ISO9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
In standard fumigation wooden box
Product Description
25kg-50kg big woven bag rice packing machine
25kg-50kg big woven bag rice packing machine is one kind of semi automatic rational weighing filling bagging equipment. It is mainly designed and developed by our own technican team for all kinds of fertilizer, rice, sugar, salt, starch etc which has the demand on stainless steel material. With bag edge flanging device, it can fold the bag edge so as to meet the no leakeage bagging demand on the fertilizer and powder industries.
|
1. | PLC micro processor control,It is easily to see with digital screen display; |
2. | Exactly to weight and high precision; |
3. | Easily to set, memory, modify the weighing scales as per demand; |
4. | Auto function of count the total filling tons and bag numbers; |
5. | Auto weighing, discharging, clamping the bags; |
6. | Auto or semi-auto reduce the bags weight exclude the granules; |
For better meet the production on the rice packing bagging, it was born the folloing structure:
Main filling Machine | 1. | display screen with PLC control instrument |
2. | flowing with vibrating feeding in fast, middle, low speed. | |
3. | Auto memory function of shift capacity, daily capacity, cumulative capacity | |
4. | Auto feeding with Infrared sensor | |
5. | Sensor control the bag clammper | |
Belt Conveyor | 1. | length:3000mm |
2. | width:400mm | |
3. | speed: 5-20m/min (adjustable) | |
4. | max capacity: 15 bag/ min | |
5. | Motor: AC380V-- 0.37kw | |
6. | belt:PVC green belt without interface. | |
Sewing Machine | 1. | Max sewing thickness:8mm |
2. | Sewing speed:1700rpm~1800rpm | |
3. | Stitch length: 6.5 mm~11mm | |
4. | Motor power:380v 50hz | |
5. | Can be rise or fall |
Technical Data
Model | DCS-10 | DCS-25 | DCS-50 |
Rated Packing Weight(kg) | 1-10 | 10-25 | 10-50 |
Division Value(g) | 2 | 5 | 10 |
Packing Accuracy | X(0.2) | X(0.1) | X(0.1) |
Packing Speed(bag/h) | 300-420 | 300-600 | 300-420 |
Power | AC220 150W | ||
Air | Compressed Air0.4-0.8MPa 1m³/h |
Manual Bag placing→Automatic filling→Automatic weighing→Automatic bag conveying→Automatic bag sewing/ sealing by manual assist.
Working Instructions of rice bagging site.
Packing Site of rice bagging machine.
Our other main supporting machine for rice bagging machine.
Xinxiang Hongyuan Vibratory Equipment Co., Ltd. is one of the famous enterprises that manufacture and sell equipments for screening, conveying, elevating, filling and bagging .
The company is specialized in the manufacturer, sales and research of vibrating screen and non-vibrating screen equipment, conveying equipment (screw conveyer, belt conveyer, drag conveyor, vibrating conveyor, magnetic conveyor, high-pressure conveyor and so on), as well as elevating equipment (TD series elevator, NE series elevator, vertical elevator and high-pressure elevator). Presently there are over 200 employees, among them, 65 have professional titles of middle and senior. In the year of 2000, the CAD work station was established by the company, which is an earlier one in the same field. Moreover, our products have scientific design, high performance and reasonable price. Depending on the first-rate products, as well as the advanced technology and equipment, highly competent personnel, strict management, and complete inspecting measures, the company has won a high repuation.
Our Services
24 hours within 7 days for pre sales consultance >> timely technical support from our professional engineers >> professional arrangement for packing and shipping >> Professional guidance for mahcine installation >>24 hours within 7 days for after sales service.
Contact Us by Tel: +86-155-6025-0277 or e-mail: cnhongyuan@
For more on 25kg-50kg big woven bag rice packing machine.
Company Profile
Xinxiang Hongyuan Vibratory Equipment Co., Ltd. is one of the famous enterprises that manufacture and sell equipments for screening, conveying and elevating. The company is located in the Hi-tech Development Zone of Henan Xinxiang, which is the largest manufacturing base of vibrating screen in China. The city of Xinxiang also has the advantage of convenient transportation, as the Yellow River is in the north of it, the Beijing-Hong Kong-Macau Expressway is in the east of it, and the Beijing-Guangdong Railway is in the west of it.
The company is specialized in the manufacturer, sales and research of vibrating screen and non-vibrating screen equipment, conveying equipment (screw conveyer, belt conveyer, drag conveyor, vibrating conveyor, magnetic conveyor, high-pressure conveyor and so on), as well as elevating equipment (TD series elevator, NE series elevator, vertical elevator and high-pressure elevator). Presently there are over 200 employees, among them, 65 have professional titles of middle and senior. In the year of 2000, the CAD work station was established by the company, which is an earlier one in the same field. Moreover, our products have scientific design, high performance and reasonable price. Depending on the first-rate products, as well as the advanced technology and equipment, highly competent personnel, strict management, and complete inspecting measures, the company has fostered a good image.
Aiming at high quality and satisfying service, and based on the principles of honesty, pragmatism, innovation and diligent, the company does welcome the old and new customers to communicate and corporate with us.
For over ten years, the company has devoted itself into the manufacture and development of vibratory equipment, which includes vibrating screen and non-vibrating screen, conveyor, feeder, vibrating motor, elevator, etc. In addition, the company not only has the excellent equipment, but also has a comprehensive marketing and after-sale service network all over Asia. Before sales, this network can provide technology support; for sales, it can provide help for business negotiation; and after sales, it can provide guide for installation and application. All in all, this network can assure you satisfying service in the whole process.
At last, the company does want to express the heartfelt thanks to the trust and support of the old and new customers. It is hoped that we can make progress and create a bright future together! Hongyuan does welcome you!
