lump cassava blocks bagging machine, packaging machine
lump cassava blocks bagging machine, packaging machine is one kind of new types semi automatic multifunctional filling bagging weighing sewing packaging machine for cassava, cassava blocks, cassava pieces, coal granules and powder. It is designed and developed by our own technical team which is cater for the non pollution trending for the environment.
| 1. | It is easily to see with digital screen display. |
| 2. | Exactly to weight and high precision. |
| 3. | Easily to set, memory, modify the weighing scales as per demand . |
| 4. | Auto function of count the total filling tons and bag numbers |
| 5. | Auto weighing, discharging, clamping the bags. |
| 6. | Auto or semi-auto reduce the bags weight exclude the granules |
| 1. | Main Filling Machine | 1. display screen with PLC control instrument |
| 2. | Belt Conveyor | 1. Length: 3000mm; 2.width: 400mm; 3. Speed: 5-20m/min(adjustable); 4. max capacity: 15 bag/ min 5. Motor:AC380V-- 0.37kw; 6. Belt:PVC green belt without interface. |
| 3. | Sewing Machine | 1. Max sewing thickness:8mm 2.Sewing speed:1700rpm~1800rpm 3.Stitch length: 6.5 mm~11mm 4. Motor power:380v 50hz 5. Can be rise or fall |
| Model No. | DCS-50 | |
| Rational Weight | 30-120kg | |
| Weighing Speed | 280 bag/ hour | |
| weighing error | ±0.2kg | |
| Max Granule Size | 100mm | |
| Motor Power | top belt conveyor | 0.75kw |
| below belt conveyor | 0.37kw | |
| sewing machine | 0.25kw | |
| air pump | 2.2kw | |
| Power Control | 0.09kw | |
| machine weight | 600kg | |
| machine dimension | 3100*1400*3400 | |
TD215 movable bucket elevator for lump cassava blocks bagging machine, packaging machine.
Belt Conveyor for lump cassava blocks bagging machine, packaging machine.
Bucket Elevator for Vertical Lifting (Click the picture for details)
Xinxiang Hongyuan Vibratory Equipment Co., Ltd. is one of the famous enterprises that manufacture and sell equipments for screening, conveying and elevating. The company is located in the Hi-tech Development Zone of Henan Xinxiang, which is the largest manufacturing base of vibrating screen in China.
We are specialized in the manufacturer, sales and research of vibrating screen and non-vibrating screen equipment, conveying equipment (screw conveyor, belt conveyor, drag conveyor, vibrating conveyor, magnetic conveyor, high-pressure conveyor and so on), as well as elevating equipment (TD series elevator, NE series elevator, vertical elevator and high-pressure elevator). Presently there are over 200 employees, among them, 65 have professional titles of middle and senior. In the year of 2000, the CAD work station was established by the company, which is an earlier one in the same field. Moreover, our products have scientific design, high performance and reasonable price. Depending on the first-rate products, as well as the advanced technology and equipment, highly competent personnel, strict management, and complete inspecting measures, the company has fostered a good image.
24 hours within 7 days for pre sales consultance >> timely technical support from our professional engineers >> professional arrangement for packing and shipping >> Professional guidance for mahcine installation >>24 hours within 7 days for after sales service.
Contact Us by Tel: +86-155-6025-0277 or e-mail: cnhongyuan@
For more on lump cassava blocks bagging machine, packaging machine.
