Specifications
1.High quality.2.Reasonable price.
3.Easy operation.
4.ISO9001:2008
ncrete mixer truck with good mixing
3 cubic meters mini concrete mixer truck with light concrete mixer turck weight
It uses eight M16 U-bolts, nuts and special sizing blocks which connected together with the truck's batholith and make up the concrete mixing truck. It's main purpose is to delivery the machine mixed concrete to the designated location, at the same time it can also be used as concrete mixing drum.
Fetures of 3m3 concrete mixer truck
It's features is to use diesel engine and power source, and the drum will be running on the way to designated location, to prevent water separate from concrete which will ensure the concrete's quality.
Workshop photos of concrete mixer truck
♦ Mixing tank adopts wear resistant manganese steel plate, the mixing tank through
the introduction of automatic welding automaticwelding system, improve the production efficiency and welding quality more fine refinement.
Parameters of 3m3 concrete mixer truck
Type |
HYC-3 |
HYC-4 |
HYC-5 |
HYC-6 |
Mixing drum capacity(m³) |
3 |
4 |
5 |
6 |
Geometric capacity of mixing drum(m³) |
5.05 |
6.15 |
7.25 |
8.7 |
Loading ration |
0.62 |
0.62 |
0.62 |
0.62 |
Feed speed(m³/min) |
3 |
3 |
3 |
3 |
Discharging speed(m³/min) |
1 |
1 |
1 |
1 |
Axis angle |
16°±15 |
16°±15 |
16°±15 |
16°±15 |
Stirring speed(r/min) |
0-12 |
0-12 |
0-12 |
0-12 |
Inlet height(m) |
3.38 |
3.5 |
3.65 |
3.8 |
Outlet height(m) |
1 |
1 |
1 |
1 |
Mixing drum diameter(m) |
1.7 |
1.7 |
1.85 |
2 |
Outline dimensions(m) |
3.95*1.9*2 |
4.45*1.9*2 |
4.95*2*2.1 |
5.28*2.1*2.3 |
Welcome to our factory
