Machine Introduction:
This series briquette press machine is excellent in briquetting machinery industry. These briquettingequipments can be used to press various powders such as coal powder, iron powder, coking coal, slag, oxidation iron sheet, carbon dust, gypsum, tailings, sludge, kaolin,active carbon and burnt powder, etc. Mineral Powder Ball Press Machine applies on the industries such as refractory material, electric powder plant, metallurgy, chemical industry, energy, transportation and heating, etc.
Working Principle:
This series of briquette machine will pass the power on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
Technical parameter:
Model |
SYYQ-300 |
SYYQ-400 |
SYYQ-500 |
Power |
5.5KW |
7.5KW |
11KW |
Roller diameter |
300mm |
400mm |
500mm |
Output |
3-4T/H |
6-8T/H |
8-10T/H |
Pressure |
900kg |
1300kg |
1500kg |
Machine weight |
500kg |
1300kg |
1800kg |
Machine size |
2500*1150*1300mm |
2500*1250*1500mm |
2500*1300*1600mm |
Coal ball size |
Φ20-50mm |
Φ25-70mm |
Φ25-70mm |
