High quality wire rod bender machine with CNC system
Wire rod bender machine is CNC System,and the machine has dounble line and single line system,High quality special material and high treatment to make straightening wheels, traction wheels, the metering wheel, longer life with lower operating costs.High working efficiency,one hour can finish 1840pieces. And the machine can bend max angle is 180°
Technical data:
Working Capacity
Single Round Wire Diameter:φ4-13mm
Double Round Wire Diameter:φ4-10mm
Single Ribbed Wire Diameter:φ4-10mm
Double Ribbed Wire Diameter:φ4-8mm
Max.Bending Angle :180°
Central Mandrel Diameter:φ20-30mm
Max.Pulling Speed :100m/min.
Max.Bending Speed :1840pics/h
Rated Power
2 Servo motor:13kW+7.5kW
1 Brake motor:4kW
1 motor for air pump:4kW
Voltage:380V/415V
Average Electric Power Consumption :5kW/h
Working Environment Temperature:-5~40
Overall Size: 3500×1000×2150mm
Gross Weight: 2.5T
We can supply the price for you.
Zhengzhou Aix Machinery Equipment Co,.Ltd.is specialized in construction machine many years,our machine,such as:sttel bat cutting,steel bar bending, steel bar straightening and cutting machine,stirrup bending machine,etc. And our machine export:Ukraine, Argentina, Bulgaria,Kenya,Jordan, Malaysia,Togo,Nigeria,etc.The goods was sold very well.Hope we can establish the longstanding relationship.
1. how can got wire rod bender machine?
Dear, after your payment,we will arrange to delivery to your port, and we will send the clearance documents to you, you need find the import company to have you customs clearance,then you can got the machine.
2.In the using processing,if i have some problem, how to slove it ?
You can send me the email or call me, ans send me the picture or video to me,i will let our engineer help you solve it.
3.The terms of payment ?
T/T,Western Union,L/C,Escrow.
4.How long i can got wire rod bender machine?
It according to different country, please tell me your destination port, then i will confirm it for you.
If you want to know more information about wire rod bender machine,please let me know.
Mobile:0086-18237112101(wechat or whatsapp)
Skype:aixmachinery
