Multi-purpose Farm Tractor Loader for Sale

Name: Multi-purpose Farm Tractor Loader for Sale
Brand: Junjie
SKU: 139110259
Availability: InStock

US$ 3,000 - 3,600 MOQ: 1 Set

Key Specifications

Condition:

New

Brand Name:

Junjie

Model Number:

TZ12D

Weifang Junjie Modern Agricultural Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QingDao Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name Junjie

Model Number TZ12D

Place of Origin Shandong, China

Type Front Loader

Moving Type Wheel Loader

Certification CE Certificate

Warranty 12 Months

After-sales Service Provided Engineers available to service machinery overseas

Front end loader
Loader Model		TZ-2	TZ-3	TZ-4	TZ-6	TZ-10
Matching Tractor	HP	15-25	20-40	30-55	45-60	70-100
Max.Lifting Height at Implement Pivot Pin	mm	2350	2550	2740	3010	3710
Dumpling Height	mm	1730	1840	2100	2370	2720
Overloading Height	mm	2170	2370	2560	2830	3490
Dumpling Distance	mm	370	500	600	640	740
Ground clearance at Arm Prvot Pin	mm	1120	1200	1360	1500	1780
Max.Tip in Angle	Degree	48	48	48	48	54
Tip out Angle	Degree	52	58	58	58	58
Crowd angle at lowered lift arm	Degree	140	135	135	135	145
Digging depth	mm	90	100	100	120	180
Lifting Force at Implement Pivot Pin	Kg	1821/1184	2224/1474	2144/1321	2150/1286	2308/

Front end loader
Loader Model		TZ-2	TZ-3	TZ-4	TZ-6	TZ-10
Matching Tractor	HP	15-25	20-40	30-55	45-60	70-100
Max.Lifting Height at Implement Pivot Pin	mm	2350	2550	2740	3010	3710
Dumpling Height	mm	1730	1840	2100	2370	2720
Overloading Height	mm	2170	2370	2560	2830	3490
Dumpling Distance	mm	370	500	600	640	740
Ground clearance at Arm Prvot Pin	mm	1120	1200	1360	1500	1780
Max.Tip in Angle	Degree	48	48	48	48	54
Tip out Angle	Degree	52	58	58	58	58
Crowd angle at lowered lift arm	Degree	140	135	135	135	145
Digging depth	mm	90	100	100	120	180
Lifting Force at Implement Pivot Pin	Kg	1821/1184	2224/1474	2144/1321	2150/1286	2308/
