Polyester fiber cutting machine/polyester staple fiber machine/polyester film cutting machine
Introduction of Carbon fiber cutting machine /glass fiber chopping machine/ Carbon fiber chop Machine / Glass fiber cutting machine/ Para Aramid fiber cutting machine
This is the short size fiber cutter,glass fiber cutting machine / aramid fiber cutting machine.It is specially used for carbon fiber , metal fiber and the aramid fiber to make construction material , special paper making , paint making and other process.
Carbon fiber cutting machine /glass fiber chopping machine/ Carbon fiber chop Machine / Glass fiber cutting machine/ Para Aramid fiber cutting machine parameter
Model |
KLC-140 |
KLC-160 |
Cutting Length |
1-80mm |
1-100mm |
Feeding width |
140mm |
160mm |
Cutting Thickness |
16mm |
25mm |
Cutting speed |
140-180times/min |
200-260times/min |
Cutting capacity for Aramid ;6mm length |
25-30kg/h |
90-100kg/h |
Motor power |
1.5kw ,380V |
3.0kw ,380V |
Weight |
500kg |
800kg |
Carbon fiber cutting machine /glass fiber chopping machine/ Carbon fiber chop Machine / Glass fiber cutting machine / Para Aramid fiber cutting machine photos show
cutting chopping glass fiber
cutting /chopping carbon fiber
chopped fibers(glass fiber, carbon fiber,aramid fiber)
chopped carbon fiber and carbon fiber powder
cutting chopping aramid fiber
We also have big model carbon fiber cutting machine!
carbon fiber cutting machine/ Carbon fiber chop Machine / Glass fiber cutting machine / Para Aramid fiber cutting machine packing
