Broiler Chicken Scalding Machine/Scalder for Poultry Chicken
Structure Features
1.all made of stainless steel ,meet the needs of food hygienic standard
lsed box structure,minimum steam loss
3.heat exchange methond is adopted to avoid scalding poultry body
4.pneumatic turbulent mixing ,the temperature uniform ,full of scalding
5.equipment assembly structure ,can be assembled into a different model
Poultry Slaughter Machine
1.Killing conveyor line
Chicken will be processed on this rail, it is main part for the main slaughter plant Production line.
The distance of hangers is 8inch.
Stainless steel chain, guide rails, stainless steel hooks, nylon hanger
2Electric tunning machine
fiberglass reinforced plastic
reliable and stable electrical devices
L=1.5METERS
3Scalding machine
This machine is used to scald the carcass of the chicken to remove the feather easily;
Size:4000mm×950mm×2400mm.
Thickness of Board: 2mm,Upper Cover Thickness :1.2mm,Supporting Leg Thickness:2mm.
Temperature between 58C°-61C° of the water
use blower system and impact pressure system make to produce highly scalder results.
Power:6KW
4A Frame Primary Plucker
This plucker is dedicated device for chickens ,there are 4 main parts: Depilation, regulation section, guide part, spray part.
Principal part is stainless steel
Shape Size:3350*2350*2350
De-feather Machine consists of four boxes .Each line has 12 plates .Total 6 lines with 72plates.
Power :3KW *6=18kw/set
5Automatic cut head machine
this equipment use to auto cut the head on production line
Principal part is stainless steel
6Automatic cut claw machine
this equipment use to auto cut the feet on production line
Principal part is stainless steel
this equipment use dedicated accurate chuck location had high quality feet
7Unloading claws device
this equipment will be auto take off the feet from production line
All body is stainless steel
8Drivng device
This machine is to run the whole hang rail
including: motor , reducer , brackets and other drive components
Power:2.2KW By inverter power, run more smoothly.
9Frequency converter
Frequency Controlling Box.
Stainless steel Box
3.7kw
10Tension device
To control the convey rail length and tight
Stainless steel structure
11Spiral precooling machine
This device can replace the precooling line to precooling the chicken carcass
This machine used to low down the temperature of carcass to keep the carcass good-looking and keep fresh in the forward process.
The Thickness of the tank made of 3 stainless steel
Spiral Pushing Device is melted by 2mm thick stainless steel.
Power 5.2kw/set
ONE sets of Fan to make bubbles in the water in the tank efficiently so that improve cooling result and clean the carcass too
Shape Size:L=5000*2160*H
Buyer Also Need To Prepare cold Water Or A Piece Of Ice MachineBuyer prepare workspace
Packaging :wrapped in wrapping film before packing which is to avoid moisture on the sea ,this machine is put in wooden/iron crate based on good protection purpose and export standard .
Delivery Detail:15-30 working days
Service before sale
1.24 hours online .Your inquiry will be quick reply by email .
Also can go through all questions with you by any online chatting tools (Wechat ,Whatsapp ,Skype ,Viber ,QQ , TradeManager )
2.Professionally and patiently introduction,details pictures and working video to show machine
Service on sale :
1.Test every machine and inspect the machine seriously .
2.Send the machine picture which you order , then packing it with standard export wooden box after you confirm the machine is ok .
3.Delivery:If ship by sea .after delivery to seaport .Will tell you the shipping time and arrival time . Finally, send all original documents to you by Express For Free.
If delivery it by Express to your door(DHL, TNT,Fedex, etc) or by air to your airport, Or logistic to the warehouse which you request . We will tell you the tracking number after delivery.
Service after sale
1.Free insurance for goods
2.24 hours online to solve any problem . Supply you English manual book and technical support , maintain and install video to help you solve the problem, or dispatch worker to your factory.
we will try our best to satisfy you !
