Organic fertilizer disc granulator/ fertilizer granulating disc for the africa market
- 1500 Set / Sets per Month
- qingdao tianjin shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Application: | make kinds of fertilizer, Organic Fertilizer ,inorganic Fertilizer, manure fetilizer ,BB compost | Production Capacity: | 1-15tph |
Place of Origin: | Henan, China | Brand Name: | YH-ypzlj | Model Number: | refer to the model of the machine |
Power(W): | refer to the model of the machine | Dimension(L*W*H): | refer to the model of the machine | Weight: | refer to the model of the machine |
Features: | ferilizer | Certification: | ISO9001-2008,CE | Warranty: | two years |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
fertilizer disc granulator1.supply the complete drawing
by the customer requirement
3.best price
4.ISO9001-2008,CE
Organic fertilizer disc granulator/ fertilizer granulating disc for the africa market :
Introduction of fertilizer disc granulator
The disk angle of the fertilizer disc granulator is arc and its granulating ratio is over 93%
which is higher among all types of fertilizer granulator The fertilizer granulating machine has
3 mouths that are used to discontinuously produce fertilier granules, which reduces
labor intension and improve labor efficiency. The bottom of the disk/ fertilizer disc granulator is supported by several armor plates solidly. The fertilizer disc granulator is the best choice for your requirement to make organic fertilizer granules with raw materials of chicken manure,sheep manure, cattle manure,human waste and so on. But if you would like to make NPK compound fertilizer, using rotary granulator is the best choice for you.
Working principle of fertilizer disc granulator
Adjust the balling disc between 40 ° -55 ° angle. Raw material powder in a fertilizer mixer is evenly moistened by atomized water , then delivered the raw materials into the fertilizer pan granulator. The raw materials moisture should be controlled at 20 to 30%. The materials powder are added directly into the disc fertilizer granulating machine, and pan granulator will rotate in specific speed . Due to adhesion and plasticity of the material, the pellets bond with each other and grow up gradually in the course of the campaign.
Raw materials for fertilizer disc granulator
Raw materials for making organic fertilizer can be animal manure like chicken manure,sheep manure,cow manure, organic waste, straw meals,grass meals,human waste and so on. Beside you can also add some micro element like compound materials. the fertilizer pan granulator require the moisture is 20--30%,if it is above this, using our new design organic fertilizer pellet making machine is best choice.
Technical Parameter of the fertilizer disc granulator
Specification (m) | Rotation speed of disk (r/min) | Capacity(t/h) | Power(kw) | Adjusting range of disk gradient | Dimensions( m ) | Weight (kg) |
Ø2.2 | 14.25 | 4-8 | 7.5 | 35-55 | 2.8*2.75*2.58 | 2850 |
Ø2.5 | 11.81 | 5-10 | 7.5 | 35-55 | 3.2*2.3*3 | 3250 |
Ø2.8 | 11.21 | 12-16 | 7.5 | 35-55 | 3.4*2.6*3.1 | 3710 |
Ø3.0 | 11.3 | 15-18 | 11 | 35-55 | 3.7*2.7*3.3 | 4350 |
Ø3.2 | 9.6 | 15-20 | 11 | 35-55 | 3.9*2.7*3.4 | 5110 |
Ø3.6 | 9.1 | 18-24 | 15 | 35-55 | 4.3*3.1*4.0 | 6510 |
5-30t/h urea melt spraying granulation production line ,
10-30t/h Sulfur based NPK Ammoniation granulation production line ,
1-30t/h New style controlled release fertilizer production line ,
1-30t/h Organic fertilizer, Amino acid, Living garbage, waste, etc, Biological fertilizer line.
1-30t/h Bulk Blending (BB) fertilizer production line
remarks:the complete fetilizer production line are including in following equipments
1. Disc Mixers or automatic feeding system
2. Crasher
3. Disc Granulator(Rotary Drum Granulator)
4. Rotary Dryer
5. Rotary Cooler
6. Rolling and Sieving machine
ater
9. accessories
