Home small electric grinding mill
Features and advantage:
1. High ratio of crushing
2. Equal product granularity
3. Simple structure, easy operation
4. Convenient requirement
5. Low consumption
6. Working by diesel engine or motor
This Home small electric grinding mill is smashing equipment for processing block material or rod -like material in to forage and animal feeds. it is mainly suitable for corn, corn stalk, peanut shell, bean stalk and so on.
Its working principle is material from the hopper into the crushing chamber, there have been high-speed rotating hammer crushing blow, under the action of centrifugal force to break the material along the outer edge of the rotor, continuous film by the hammer, tooth plate, screen film extrusion, collision, combat, rubbed and was quickly crushed, crushed powder after the centrifugal rotor by the pressure and suction force of the fan sent outside the aircraft through the sieve, sieve the powder through repetition but on top process until the machine through the sieve was sent to the far outside.
Animal Feed Grinder Specification
Item |
Specification |
Model |
9HFQ-36 |
Overall dimension: |
850*630*800 |
Overall weight |
100Kg |
Rotor diameter |
360mm |
Matched power |
5.5-7.5KW/380V |
Diesel engine |
10HP |
Speed of main spindle |
4600r/min |
Hammer speed |
86.7M/S |
Size of input granules |
202mm |
Clearance between hammer & sieve surface |
10mm |
Hammer No. |
12 |
Hammer arrangement |
staggered parallel arrangement |
Sieve disc width |
200mm |
Sieve disc cornerite |
180o |
Sieve pore specification |
0.5mm – 5mm |
Fan impeller diameter |
260mm |
|
Productivity for sieve pore diameter 2mm: Corn: 500-650KG Corn stalk: 80-150KG Peanut shell: 300-500KG Bean stalk: 130-230KGDifferent grain and crops has different productivity Other type machines (different output) are available. | |
