US$ 1 - 2 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
zdcard
Model Number:
Smart Card
Contact Supplier Request Quote Chat Now
Shenzhen ZDCARD Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name zdcard
Model Number Smart Card

Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

java card smart card! Dual Interface JCOP 2.4.1 J3A040 21- 36K Java CPU smart Card

Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Product Description



Java Card tech provides a secure environment for applications that run on smart cards and other devices with very limited memory and processing capabilities. Multiple applications can be deployed on a single card, and new ones can be added to it even after it has been issued to the end user.



Java Card Open Platform (JCOP) is an operating system for smart card or security sensitive embedded system environment. The functional architecture can be partitioned into 3 parts:

Java Card, for development of applications, i.e. API and structure of card applets similar to class files Global Platform, for administration of applications and operating system,

i.e. loading and access control
JCOP proprietary features, mainly Java Card API extensions, i.e. ECC primitive calculation or DESFIRE management
We ZDCARD proudly provides following Java based smart card with personalized.
The chip forms cover from Contact, Contactless and Dual Interface.

java card smart card! Dual Interface JCOP 2.4.1 J3A040 21- 36K Java CPU smart Card

Our default J2A040 JAVA card, with COS provided by NXP, and with the TK (Transport Key) value, if you are the first to use such a card, makes sure you know how to load the TK value and initialization.

We will provide you with this JAVA card instructions and T = 0 and T = 1 initialization scripts and instructions for your initial use.
If you have used this card before, please provide ATR value and T = 0 or T = 1 of the information to us, we can help you initialized before shipping.
 java card smart card! Dual Interface JCOP 2.4.1 J3A040 21- 36K Java CPU smart Card
NXP J2A040 chip CPU card JCOP 40K capacity compatible with JCOP21-36K card can be produced to PSAM card, hico magnetic strip cards also available. cancan white card and printed cards can be offered.



 Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Product Name

UCOS 3.0 JCOP Chips & Smart Cards

Java Series Chip & Smart Card

Product Life Status

Product in certification--Sample avaliable

Certification

BCTC Certified(PBOC 3.0, PBOC 2.0)

NSICCS Certification expected for March, 15

VISA, MasterCard Certification expected for September, 15

Main Characteristics

ROM Applets

Dual PBOC 3.0, Dual PBOC 2.0, NSICCS 1.1, Dual PSE 1.2

EEPROM Applets



User Memory Available

40K~80Kbytes

Standard Compliance

JC Release

2.2.1

GP Release

2.1.1

Contact Interface

Standard Compliance

ISO 7816

T=0

Yes

T=1

Yes

Contactless Interface

Standard Compliance

ISO 14443-2, -3, -4 Type A with Mifare 1K emulation

T=CL

Yes

Baud Tate

106Kbit/s, 212Kbit/s, 424Kbit/s in both ways

Operating Frequency

13.56MHz

Cryptographic Algorithms

DES/3DES

Yes

AES

Yes: 16,24 and 32 btyes

RSA

Yes up to 2048 bit

SHA1

Yes

SHA256

Yes

Card Body

Chip From/Type

Contact, Contactless, Dual Interface

Various module industrial packaging forms on demand

Antenna

Full size(restricted embossing area)

Standard Compliance

ISO 14443-1 compliant, etc.

Material

Banking grade PVC with overlay for posting personalization

Technology

Hot lamination etc regular card manufacturing technologies

Magnetic Stripe

ISO 7811 -4, -5 compliant



chip option

 NXP JCOP Chip JAVA card CPU card: Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K



Code

Brief Name

Platform/Spec

Memory (bytes)

Interface

CJ3A040

J3A040

JCOP 2.4.1

40k

Dual Interface

CJ3A080

J3A080

JCOP 2.4.1

80k

Dual Interface

CJ3A081

J3A081

JCOP 2.4.1

80k

Dual Interface

CJ0BLA5

JCOP31/36k

(Mifare1K Emulation )

JavaCard 2.2.1

Visa GlobalPlatform 2.1.1

36k (Mifare 1K)

Dual Interface

CJ0BLA3

JCOP31/72k

(Mifare1K Emulation)

JavaCard 2.2.1

Visa GlobalPlatform 2.1.1

72k (Mifare 1K)

Dual Interface

CJ0BLA8

JCOP31/72k

(Mifare 4K Emulation)

JavaCard 2.2.1

Visa GlobalPlatform 2.1.1

72k (Mifare 4K)

Dual Interface

CJ0BLA4

JCOP41/72k

(Mifare 4K Emaulation)

JavaCard 2.2.1

Visa GlobalPlatform 2.1.1

72k (Mifare 4K)

Dual Interface



Contact CPU card chip: J2A040, J2A080, etc..
Dual interface CPU card chip: J3A041 J3A081, etc..
Customized COS model:
P5 series: P5CD012,P5CD020,P5CD040,P5CN080,P5CD128,P5CD145,etc..
P6 series: P60D024,P60D040,P60D080,P60C040,P60C080,P60C144,etc..
 java card smart card! Dual Interface JCOP 2.4.1 J3A040 21- 36K Java CPU smart Card
Kindly notice:  JCOP 10, JCOP 21, JCOP 31 and JCOP 41 chips were stopped production and compatible with J2A,J3A!

 Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Picture:

Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

 Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

 Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

 Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

 Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

 Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

 Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36KJava CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Packaging & Shipping

 Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36KJava CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;
2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods!

java card smart card! Dual Interface JCOP 2.4.1 J3A040 21- 36K Java CPU smart Card

Our Services

 JCOP 21-36K compatible,  dual interface JAVA J2A040 chip cardJava CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

Java CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36KJava CPU smart Card Dual Interface. JCOP 2.4.1 J3A040 21- 36K

FAQ



1.What about the sample testing?

  • We are very glad to send our clients' free samples for testing.What you paid only is the freight cost of the samples.

2.What about the payment?

      You can payment to us with  TT, Western Union

java card smart card! Dual Interface JCOP 2.4.1 J3A040 21- 36K Java CPU smart Card chip cardPU card

3.What about the shipping?

      We offer shipping by air-express, such as UPS, DHL, Fedex, etc. or by sea

java card smart card! Dual Interface JCOP 2.4.1 J3A040 21- 36K Java CPU smart Card



4.When is convenient to visit your factory?

  • The working days of our company and factory is 9:00-12:30,14:00-18:00 from Monday to Friday.
  • We will arrange our driver to pick up you anywhere in shenzhen if you decide to visit our factory.
