Environment Friendly Fire Wood Briquette Making Equipment
US$ 8,000 - 35,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Application:
Biomass Fuel
Production Capacity:
99%
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo/Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Output Fire Wood Briquette Press EquipmentUS$ 8,000 - 35,000MOQ: 1 Set -
Used Wood Briquette Press Equipment to Make High Density Wood LogUS$ 8,000 - 35,000MOQ: 1 Set
-
Hot Sale Briquette Equipment From Used Wood SawdustUS$ 8,000 - 35,000MOQ: 1 Set
-
Low Energy Consumption Wood Sawdust Hydraulic Press Equipment With CE CertificatedUS$ 8,000 - 35,000MOQ: 1 Set
-
Wood Chips Sawdust Briquette Press Equipment With CE CertificatedUS$ 8,000 - 35,000MOQ: 1 Set
Application
Biomass Fuel
Production Capacity
99%
Place of Origin
Shanghai, China
Brand Name
Shanghai Yuke
Model Number
YKB20A
Voltage
380V
Power(W)
75kw
Dimension(L*W*H)
1800*3800*1700mm
Weight
8000kg
Features
Mechanical Stamping
Condition
New
Certification
CE / ISO-9001/Gost
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
Fire wood briquette making equipment
Fire wood briquette making equipment is a die and ram type mechanical press with two flywheels. Each flywheel is driven by belts with motors. Material is continuously fed through a hopper by belt conveyor with its own gearbox and a motor. From feeding chamber, raw material is compressed by ram through taper bore die. Briquettes comes out from cooling track. Total process is continuous and controlled by electric panel. Briquetting press is used for producing high density fuel briquettes
Detailed Images
Fire wood briquette making equipment from sawdust
1.Screw conveyor
2.Feeding hopper
3.Main press equipment
4.Control cabinet
5.Oil cooling equipment
6.Output line
2.Feeding hopper
3.Main press equipment
4.Control cabinet
5.Oil cooling equipment
6.Output line
Specifications
Raw Material(sawdust) --wood briquette equipment-- finshed product (wood log)
Index Of Briquette
1.Density of briquette :1.1-1.3g/cm3 2.Heating value :3700-5000kcal
3.Sulfur dioxide emissions: 0.38% 4.Carbon dioxide emissions: 0.22%
5.Ash content 3.6%, and the ash could be recycled as agricultural potash, which can realize green recycling.
Our Customers
YUKE products have been a nationwide hot sale ,and exported to various countries and regions aroubd the world such as India ,Malaysia,Vietnam,Philippines,Indonesia,Thailand ,Russia,Africa,South America,Europe,etc.In the industry ,our products have won great popularity and recognition among users.
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to install the machine, training how to use the machine.
*Readily available spare parts.
*Our engineers can provide service overseas.
.
