Pathfinder Irrigation Drip Tape

Pathfinder Irrigation Drip Tape thumbnail-1
Pathfinder Irrigation Drip Tape thumbnail-2
Pathfinder Irrigation Drip Tape thumbnail-3
Pathfinder Irrigation Drip Tape thumbnail-4
Pathfinder Irrigation Drip Tape thumbnail-5
Pathfinder Irrigation Drip Tape photo-1
Pathfinder Irrigation Drip Tape photo-2
Pathfinder Irrigation Drip Tape photo-3
Pathfinder Irrigation Drip Tape photo-4
Pathfinder Irrigation Drip Tape photo-5
US$ 70 - 120 MOQ: 1 Pallet
Key Specifications
Get Latest Price
Place of Origin:
Spain
Brand Name:
PATHFINDER
Model Number:
Drip Tape
Contact Supplier Request Quote Chat Now
Grupo Chamartin S.a.
Payment & Shipping
Payment Methods:
Port of Shipment:
Valencia
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Spain
Brand Name PATHFINDER
Model Number Drip Tape
Material Plastic

1. Diameter: 16mm

2. Thicknesses: 0,125 mm to 0,2 mm

3. Flow: 0,36-1,13 L/H

4. Spacing: 10-40 cm Filtration: low sensitive
5. Drip tape with Largest low flow path in the drip industry and is more plug resistant than competitive tape emitters.

6. Patented clear flow path enables this periodic monitoring of Path the drip tape.

7. Drip tape with multiple inlets assure unrestricted flow to the emitter Path and restrict the particle size which can enter the emitter Path.

8. Drip tape with increased resistance to insect attack, fertilizers and organic products.

        Wall Distance Flow (a) Flow (b) Path Length. Máximum
REFERENCE

Drip tape CODE

   thickness emitters (l/h.100m) (l/h.emitter) Roll length
CODE       (mil.) (cm)       (m) lateral
                    (m)*
1109442 PATHFINDER 16-05-15-165-500 R4000 5 15 165 0,36 500 4000 295
1109443

 tape

 16-05-20-250-1000 R4000 5 20 250 0,57 1000 4000 210
1109444   16-05-20-365-2000 R4000 5 20 365 0,82 2000 4000 160
1109445   16-05-20-510-3000 R4000 5 20 510 1,13 3000 4000 210
1109446   16-05-30-340-3000 R4000 5 30 340 1,13 3000 4000 175
1109447   16-05-10-1020-3000 R4000 5 20 510 1,13 3000 4000 135
1109448   16-05-10-1020-3000 R4000 5 10 1020 1,13 3000 4000 85
1109449   16-06-15-165-500 R3200 6 15 165 0,36 500 3200 295
1109450   16-06-20-250-1000 R3200 6 20 250 0,57 1000 3200 210
1114001   16-06-20-365-2000 R3200 6 20 365 0,82 2000 3200 160
1109451   16-06-20-510-3000 R3200 6 20 510 1,13 3000 3200 210
1109452   16-06-30-340-3000 R3200 6 30 340 1,13 3000 3200 175
1109453   16-06-20-510-3000 R3200 6 20 510 1,13 3000 3200 135
1110214   16-06-10-1020-3000 R3200 6 10 1020 1,13 3000 3200 85
1115712   16-08-15-165-500 R2500 8 15 165 0,36 500 2500 295
1115713   16-08-20-250-1000 R2500 8 20 250 0,57 1000 2500 210
1115714   16-08-20-365-2000 R2500 8 20 365 0,82 2000 2500 160
1115613   16-08-40-255-3000 R2500 8 40 255 1,13 3000 2500 210
1110573   16-08-30-340-3000 R2500 8 30 340 1,13 3000 2500 175
1110561   16-08-20-510-3000 R2500 8 20 510 1,13 3000 2500 135
1112215   16-08-10-1020-3000 R2500 8 10 1020 1,13 3000 2500 85





DENOMINATION: Diameter drip tape - Wall thickness (mil.) - Spacing (cm) - Flow (l/h. 100 m) - Path - Reel length (m)

Example: 16 - 06 - 20 - 510 - 3000 - R3200

WALL THICKNESS: 1 mil. = 1 mil. inch = 0,025 mm / 6 mil. = 0,15 mm / 8 mil. = 0,20 mm

FLOW: (a): l/h. 100 m = litres per hour per 100 metres of tape @ 0.55 bar

(b): l/h. emitter = litres per hour per emitter @ 0.68 bar.

Ask for other wall thickness, spacing and flow

Pathfinder irrigation drip tape
