1BZDZ series Hydraullic Disc Harrow
1BZDZ series wing-folded heavy-duty disc harrow are mainly used for cleaning away stubble of plants before tillage,or crushing clods after tillage on uncultivated land and in sticky heavy clay soil fields,they can also be used as a plough for primary tillage in dry culdtivated fields. The series produced are all fitted with hydraulic rubber wheel for transportation.It is easy to be transported and change direction on the edge of fields.
Technical parameters:
Model |
Unit |
1BZDZ-4.4 |
1BZDZ-4.8 |
1BZDZ-5.3 |
1BZDZ-6.2 |
Overall dimension |
mm |
5800×4500×1500 |
5800×4950×1500 |
5800×5400×1500 |
5800×6380×1500 |
Weight |
kg |
3100~3150 |
3250~3300 |
3400~3450 |
4150-4200 |
Working width |
m |
4.4 |
4.8 |
5.3 |
6.2 |
Working depth |
mm |
240 |
|||
Blade spacing |
mm |
230 |
|||
No of disc |
pc |
40 |
44 |
48 |
56 |
Dia.of disc |
mm |
660 |
|||
Transport clearance |
mm |
>260 |
|||
Productivity |
ha/h |
2.7 |
3.2 |
3.8 |
4.65 |
Matched power |
HP |
105-110 |
115-120 |
125-130 |
140-160 |
Linkage |
|
Trailed |
|||
