Home > Products > Loader & Backhoe for Tractor > Easy using hydraulic valve backhoe
Easy using hydraulic valve backhoe
- 100 Set / Sets per Month
- Qingdao port
Product Details
Condition: | New | Application: | Farm,garden,lawn | Brand Name: | GUANGDA |
Model Number: | LW-series | Dimension(L*W*H): | 2150X1300X2755 | Weight: | 800kg |
Features: | towable backhoe | Certification: | CE | Warranty: | 12 months |
After-sales Service Provided: | No overseas service provided |
Product Description
Easy using hydraulic valve backhoe
trailed by car or tractor
3 point linkage backhoe attachment
diesel and gasoline engine for choose
full side shift with independent hydraulic supports
Specification:
• PTO Pump and gear box.
• 3 Point fits most tractors with a Category 1 Hitch.
• Color's are Black or Red, paint is powder coated
• Optionable Bucket sizes 10"-22" are all interchangeable for backhoe loader.
• Reservoir Tank with Filter is optional for LW tractor backhoe loader.
Photos of the Backhoe:
Technical Specification:
Model | LW-5 | LW-6 | LW-7 | LW-8 | LW-9 |
Horsepower Range | 16-25 | 20-35 | 25-45 | 60-100 | 65-125 |
Overall size | 1550×1480×2130 | 1550×1480×2130 | 2000×1860×2500 | 2140×1860×2800 | 2300×1750×2800 |
Max. digging depth(mm) | 1720 | 1850 | 2150 | 2640 | 2900 |
Max. digging radius(mm) | 2560 | 2800 | 3360 | 3930 | 3977 |
Max. digging height(mm) | 2200 | 2500 | 3400 | 3510 | 3900 |
Discharging height(mm) | 1300 | 1400 | 1760 | 2000 | 2362 |
Max. digging depth(2ft) Flat bottom(mm) | 1600 | 1600 | 2000 | 2500 | 2760 |
Swing Angle(.) | 140 | 140 | 140 | 140 | 160 |
Bucket Rotation(.) | 160 | 160 | 160 | 160 | 150 |
Operating Digging Force(KG) | 16mpa | 16Mpa | 16Mpa | 16Mpa | 16Mpa |
Dipper stick Digging Force(KG) | 520 | 790 | 950 | 1000 | 1270 |
Shipping Weight(approx)kg | 410 | 470 | 540 | 600 | 820 |
Bucket size and Cap. | ||||||
Size(mm/inch) | 250/10 | 300/12 | 400/16 | 450/18 | 500/20 | 550/22 |
Cap.(m3) | 0.03 | 0.036 | 0.048 | 0.054 | 0.06 | 0.066 |
Pre-sales | Service online for 24hours to wait for your inquiry |
Sale tracking | Provide specification, photos, and delivery cost for you. Answer your questions and solve your problems at any time. |
After-sale service | 12months warranty for the machine without wearing parts. We will deliver damaged parts (except wearing parts) for free based on quality problem within warranty period. Wearing parts are also sold to match your machine if needed. |
After-sale service process | If some parts damaged, please take photos and shoot video firstly, please send us in time. We will pass your problems to our after-sale department to deal with. Solution will be provided for you as soon as possible. |
1. 12 months warranty since machine arrives destination port
2. T/T (Telegraphic transfer) payment: 30% as deposit, 70% balance payment shall be paid before delivery
3. delivery time: 20 working days after confirmation of deposit
4. Loading: 1*40HQ/3sets
5. Logo: can be customized and it is for free!
6. technical service offered whenever you are in need
Henan Guangda is a professional manufacturer and supplier of farm machinery, has been engaging in the international trading for 14 years. 12-180hp wheel tractor, agricultural implements and forest machinery are our main production, one-stop service is our main feature. Products are widely exported to North America, Europe, Africa, South America and Southeast Asia. Featuring high quality standards, rigorous management measures and advanced technology, we have built up very fine reputation among both domestic and overseas customers.
