High Quality Cultivator Used for Farm Tractor
- QINGDAO
- T/T
You May Like
Product Details
| Condition | New | Type | Farm Cultivator | |
| Power Type | Diesel | Certification | CE,ISO | |
| Warranty | 12 month | Use | farm use | |
| Brand Name | GUANGDA | Model Number | 3ZY series | |
| Weight | 150-290 kg |
Product Description
High quality cultivator used for farm tractor
- convenient row pitch adjustment
-large range of application
-have CE certification
The characteristic of mini cultivator :
1, after cultivation, the soil block is in small, surface is smooth, weeds and stubble covered good.
2, strengthen the cutter axis: bold type of cutter shaft, knife blocks is thickened, cutter shaft bearing increase;
3, strengthen type gear box : : bold gear box spline axis, gear modulus increase, the size bevel gear is circle-arc gear.
4, strengthen the suspension: the up suspension is channel steel, the below suspension is binaural type.
The parameter of mini cultivator :
Type | 3ZY-1.2 | 3ZY-2.0 | 3ZY-2.8 |
Working width(mm) | 1200 | 2000 | 2800 |
Working depth(mm) | 100-240 | ||
No. of plough body | 2 | 3 | 4 |
Weight(kg) | 150 | 210 | 290 |
Linkage | Three point mounted | ||
Matched power(hp) | 25 | 40 | 50-60 |
Overall dimension(mm) | 1010*900*1100 | 1400*900*1100 | 1860*900*1200 |
The features of mini cultivator :
3ZY series cultivator is developed by our company according to the demand of foreign market.
It is suitable for cultivating, loosening soil, preserving soil moisture and cutting grass in farm field. And also achieves different farming demand through change the matched plough bottoms according to the requirements of different customers. The machine is mounted with four-wheel tractor, it adopts spring tension device to tensioning plough bottom to loosen soil in stable state. By the action of spring, the bottoms could be turned back when meet obstacles or hard objects, and returned to normal working after over them, by which the bottoms are protected. The users could adjust the cultivating space and no. Of bottom to meet different demands.
24hours online to ensure quick response to customers' inquiry or online message
guide customers to choose the best suitable machine model, offer detailed specification and competitive prices
Contract execution
Machine production will be arranged strictly according to the contract
Machine photos will be sent to you for reference and inspection during production
Machines will be strictly inspected and tested before delivery
Strong enough packages to prevent possible damages during shipping
Send customs clearance documents by DHL
Keep customers to be informed of vessel location while shipping and get them prepared for customs clearance work
After-sale service
12 months warranty except for wear parts
broken spare parts (except for wear parts) will be sent for free due to quality problems
In time response to customers technical problems
New products update for customers' reference
Henan Guangda is a professional manufacturer and supplier of farm machinery, has been engaging in the international trading for 14 years. 12-180hp wheel tractor, agricultural implements and forest machinery are our main production, one-stop service is our main feature. Products are widely exported to North America, Europe, Africa, South America and Southeast Asia. Featuring high quality standards, rigorous management measures and advanced technology, we have built up very fine reputation among both domestic and overseas customers
1. Free tool box and free easy damage parts
2. Warranty: warranty time is 12 months after the goods delivery your port.
3. Color: according to your requirement
4. Logo: can stick your logos free if you need
5. Delivery time: 25 days after the down payment
6. Payment: The payment term is T/T (30% deposit in advance, 70%T/T as balance before shipment)
7. Various attachments and implements are supplied too for the tractors
8. technical service offered whenever you are in need
