Home > Products > Feed processing equipment > Nutrious cattle food manufacturing cattle feed pelletizer machine price
Nutrious cattle food manufacturing cattle feed pelletizer machine price
- 18 Set / Sets per Month
- Shanghai; Tianjing; Qingdao;Ningbo;Dalian;Alataw Pass;
- T/T
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | Guangda |
Model Number: | HKJ35 | Type: | Feed Pellet Machine | Voltage: | 380V |
Power(W): | 55 | Dimension(L*W*H): | 1000*800*900MM | Weight: | 980 kg |
Certification: | CE | Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Nutrious cattle food manufacturing cattle feed pelletizer machine price:
1. The description of cattle feed pelletizer machine:
We are professional in producing cattle feed pelletizer machine for many years, our machine can be used for both feed pellet and fuel pellet producing.
Animal cattle feed pelletizer machine is applied to different grains such as corn, wheat, sorghum, soybean meal for feed pellet and also can make full use of the forestry waste: Crops straw, husks, vines.
The feed cattle feed pelletizer machine is easy to digest by chicken, duck, pig, cow and any other livestock.The fuel pellet produced by this machine can burn fully and without smoke, it is very clean and environmental.
The final pellet is 2.5mm,3mm, 4mm, 6mm, 8mm, 10mm for feed pellet and fuel pellet.
2.The working principle of cattle feed pelletizer machine:
1).it consists of the feeder, the conditioner, the flat die and the motor;
2).firstly, the material go through the feeder from which the mateial can flow into cattle feed pelletizer machine at the best speed to make sure the ful load working of the pellet machine.
3).then the hot dry steam mix with the material and soften, steam the material for easier pelletizing, and this design can also extend its life.
4).finally,the softened and steamed material go through the flat die to be maked into pellet, we can adjust the flat die to get different size of pellets.
3. Technical parameters:
pellet making machine Type | Power of main motor | Capacity | Power of feeding motor | Power of conditioner | Diameter of ring | Size of finished pellets |
HKJ 25 | 11*2 | 0.2-0.3 | 0.75+0.55 | 2.2 | 250 | 6-10 |
HKJ32 | 37 | 0.3-0.6 | 0.75+0.55 | 2.2 | 320 | 6-10 |
HKJ35 | 55 | 0.5-0.8 | 0.75+0.75 | 2.2 | 350 | 6-10 |
HKJ40 | 75 | 0.7-1.1 | 1.5+0.75 | 2.2 | 400 | 6-10 |
HKJ42 | 110 | 1.0-1.5 | 1.5+0.75 | 5.5 | 420 | 6-10 |
HKJ508 | 132/160 | 2.0-3.0 | 1.5+0.75 | 7.5 | 508 | 6-10 |
4. How to Choose A Perfect cattle feed pelletizer machine :
Animal cattle feed pelletizer machine takes the circular motion as the principle. The press roller, main shaft and die mould are of high quality alloy steel. There are common two design of cattle feed pelletizer machine: rotating rollers with stationary die or running die with stationary rollers.
Though the two kinds of cattle feed pelletizer machine can both make wood pellets and feed pellets.
Then, let us talk about the engine of pellet press. There are two choices, flat die cattle feed pelletizer machine with electric motor and diesel engine. Electric cattle feed pelletizer machine is more energy-saving and environmental protection, while you must make sure there is enough electricity in your pellet making sites .
Picture:
Structure:
Spare parts:
Raw material:
Finished pellet samples:
Factory processing site:
Delivery and package:
Pre-Sales Service:
1) Offering comprehensive technical and business consultation services;
2) Proposing the most suitable scheme and cattle feed pelletizer machine for our clients;
3) Designing and fabricating targeted products according to the special requirements of clients;
4) Training periodically high qualified service technician.
After-sales Service:
1) Highly inspecting equipments in every working procedure, quality comes first;
2) Fast & Safe Delivery for cattle feed pelletizer machine with standard exporting packages;
3) Assisting our clients for foundation construction of equipments;
4) Dispatching engineers to install and debug equipments;
5) Training the first-line operators on site;
6) Regularly visit clients to solve production problems
7) Providing life-long maintenance service;
8) Providing technical exchanging;
If you have any need or question, please feel freely to contact Dido Fu:
Skype:DidoFu1107 E-mail:xltxc @gdbloc.com
Tel:+86-371-56668520 Fax:+86-371-55989982
Mob:+86-13073797095
or visit our company website:
We need to know:
A.What capacity would your prefer?-----The capacity for cattle feed pelletizer machine;
B.What is your raw material?-----According to different raw material(such as hard wood,soft wood,straw,rice hust), capacity is different.
C.What is your raw material size?-----Best size for pressing high quality pellets is 3mm.
D.What is the moisture of your raw material?-----Better to be 10-15%.
advantages:
