Specifications
uhf rfid metal hard tag1.Material: abs epoxy
2.Frequency: 13.56Mhz and 860-980mhz
3.Chip:alien h3
long range passive rfid uhf on metal tag
<< rfid uhf on metal tag >>
Shanghai Sparkle Safe Technology Co., Ltd. is one of the first professional RFID wristband suppliers in China. Over the years, our company has supplied millions of RFID wristband in both China and more than 80 countries worldwide. Our wristbands have passed the accreditation of ROHS, CE, FCC and CPSIA.
Automatic professional production lines Monthly output:
RFID metal tag: 50 million
metal tag hot sell in these years!
♠ Why Choose Us?
1. High Quality Control ----We have strict QC system, Twice QC lines arranged before delivering;
2. High Reputation ---- We supply products to many World Brand Companies such as Samsung and Nokia;
3. Responsible Sales ---- Good service for you from the minute very very beginning to endless future;
Introduction:
- Various area of data information auto-management.
- Metal Asset Tracking
C2319
| Technical Parameter | |
| Communication Protocol | ISO 18000-6C(EPC Class 1 Gen 2) |
| Carrier Frequency | 860-960MHz |
| Read Range | ≥3M(depends on Antenna Gain) |
| Color | Grey(can be customized, with additional payment) |
| Encapsulation Material | High-temperature endurable ABS plastic material |
| Encapsulation Dimension | 23.5*19*4.0mm |
| Weight | 48g |
| OperatingTemperature | -20°C ~ +120°C |
| Storage Temperature | -30°C ~ +150°C |
Product type |
Soft anti-metal tag |
Long aiti-metal tag |
Vehical long anti-metal tag |
FR4 anti-metal tag |
Matertial |
Wave absorbing materials |
High temperature resistant plastics ABS
|
ABS or PC |
FR4 |
Size |
customized |
long:155X32X10+-0.2mm short:79X31X9.5+-0.2mm |
249X13.8X6mm |
0921:100X11X3.2mm 0922:113X16.5X3.2mm 0923:138X22X3mm 0924:100X30X3.2mm 0925:100X30X3.2mm 0926:95X25X3.2mm 0927:97X17X3.2mm 0928:36X13X2.7mm |
Chip Available |
MF1 or customized |
G2XM or customized |
G2XM,G2XL,HSL,H3 or customized |
H3,M4QT or customized |
Frequency |
LF,HF |
LF,HF,UHF |
UHF |
UHF |
Reading range |
2.5-10cm |
More than 5.5M(9dbi antenna and 1.0W RF power) |
More than 5.5M(9dbi antenna and 1.0W RF power) |
More than 1.5m |
Working Temperature |
-10~65°C |
-10~100°C |
-10~80°C |
-10~100°C |
Craft |
epoxy |
Ultrasonic |
Ultrasonic |
3M adhesive strips |
Features |
high temperature resistance, moisture proof, anti-corrosion, anti impact, suitable for outdoor harsh environments,effectively prevent the interference of metal on the RF signal, High performance reading range. |
|||
Application |
Widely used in vehicle license plate, cylinder, cylinder, marking machines, tools, metal containers and other metal environment tracing identification, management and tracking. Suitable for outdoor power equipment inspection, tower pole elevator inspection, pressure vessel steel cylinders, various electric household appliances tracking, asset management, logistics management, automobile parts, process management, the slaughter line management. |
|||
Standard package suit for long distance transportation
Tell:+86-13817275402
Trademanager: cn1510657781
Skype: sales03sparkle
Sales Name; Candy Yang
