Bucket 1.4cbm Backhoe 0.3cbm Backhoe Loader WZ30-25

Name: Bucket 1.4cbm Backhoe 0.3cbm Backhoe Loader WZ30-25
Brand: bocheng backhoe loader
SKU: 139008241

US$ 30,000 - 37,200 MOQ: 1 Set

Key Specifications

Condition:

New

Brand Name:

bocheng backhoe loader

Model Number:

WZ30-25 backhoe laoder

Qingzhou Bocheng Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao port china

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name bocheng backhoe loader

Model Number WZ30-25 backhoe laoder

Place of Origin Shandong, China

Type Backhoe Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 5910*2268*3760

Rated Load 3T

Certification ISO Certificate

Warranty One Year

After-sales Service Provided Engineers available to service machinery overseas

bucket 1.4cbm backhoe 0.3cbm backhoe loader WZ30-25

1.backhoe capacity:3000kg
2.engine brand:Xichai YTR4108G60-1
3.rated power:55kw
4.wheel base:2.25m
5.bucket capacity:1.4cbm

The main parameters of WZ30-25 backhoe loader

Overall Operating Weight	7640KG	Final Reducer	Single Stage Final Reducer
Transport Dimension		Rated Loader of Axle	7.5t
mm LWH	591022683760	Transmission System
Wheel base	2250mm	Torque Converter
Min. Ground Clearance	300mm	Model	YJ280
Bucket Capacity	1.4m³	Type	Single-stage Three Elements
Breakout Force	38KN	Max. Efficiency	84.4%
Loading Lifting Capacity	2500KG	Inlet Pressure	0.4Mpa—0.55 Mpa
Bucket Dumping Height	2742mm	Outlet Pressure	1.2Mpa—1.5 Mpa
Bucket Dumping Distance	1062mm	Cooling Method	Oil-cooling Pressure Circulation
Digging Depth	52mm	Gearbox
Backhoe Capacity	0.3 m³	Type	Fixed Shaft Power Transmission
Max. Digging Depth	4082mm	Oil Pressure of Clutch	1373Kpa—1569 Kpa
Swing Angle of Excavator Grab	190^o	Gears	Two Gears Ahead, Two Gears Astern
Max. Pulling Force	39KN	Max.Speed	22Km/h

Engine		Tyre
Model	YTR4108G60-1	Model	16/70-20
Type	In Line Direct injection Four-Stroke and Injection Combustion Chamber	Pressure of Front wheel	0.22 Mpa
Cylinder-Inside Diameter*Stroke	4-108×120	Pressure of Back Wheel	0.22 Mpa
Rated Power	55Kw	Brake System
Rated Speed	2400r/min	Service Brake	Air Over Oil Caliper Brake
Min. Fuel Consumption	≤216g/km.h		External Type
Max.Torque	≥261.7N.M/1800r/min		Self-regulation
Displacement	4.4L		Self-balance
Steering System		Emergency Brake	Operation Power Implementing brake
Model of Steering Device	BZZ5-250	Emergency Brake	Manual Operation Power Terminating Brake
Steering Angle	±36^o	Hydraulic System
Min. turning radius	5018mm	Digging Power of Excavator Grab	46.5KN
Pressure of the system	12Mpa	Digging Power of Dipper	31KN
Axle		Bucket Lifting Time	5.4S
Manufacturer	Feicheng Axle Factory	Bucket Lowering Time	3.1S
Main Transmission Type	Double Reduction	Bucket Discharge Time	2.0S
The parameters are subject to change without notice
