10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage

10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage thumbnail-1
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage thumbnail-2
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage thumbnail-3
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage thumbnail-4
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage thumbnail-5
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage thumbnail-6
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage photo-1
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage photo-2
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage photo-3
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage photo-4
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage photo-5
10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage photo-6
US$ 2,780 - 2,980 MOQ: 4 Pieces
Key Specifications
Get Latest Price
OEM No.:
YQ/T-106TDM
Max Payload:
3500kgs
Size:
3080x1880x300mm
Contact Supplier Request Quote Chat Now
Jinhua Yong Qiang Vehicles Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
OEM No. YQ/T-106TDM
Max Payload 3500kgs
Size 3080x1880x300mm
Place of Origin Zhejiang, China
Brand Name YongQiang
Model Number YQ/T-AWA-106TDM

10X6 Hot Dipped Galvanized Hydraulic Tipper Trailer with Cage
- Aggregate trailer mass (ATM): 3500kg
- Tare weight: 1300kg
- Loading capacity (ATM less Tare): 2200kg
- Overall dimension: 5100 x 2400 x 1970mm
- Internal box dimension: 2950 x 1800 x 300mm
- Fully hot dipped galvanized
- 3-Stage Hydraulic Tipping Ram with 3000 KG Loading Capacity
- Solid Axles rated at 2000KG each
- 12” Dual Axle Electric Drum Brakes
- 100 x 50 x 3mm Box Section used on Drawbar and main Chassis
- Heavy Duty 2.5mm Checker Plate Floor and Guards all around
- 7 Leaf Heavy Duty Springs with Rocker Roller Suspension set-up
- 15 inch 6 stud brand new Sunraysia Light Truck Wheels (Land-cruiser⁄Patrol)
- 12V Automotive Battery come with the hydraulic system
- Come with Heavy Duty jockey wheel and manual parking brake
- Lockable tool box for hydraulic system
- Maintenance free LED indicators
- Opening front and rear tailgate
- Tie-down rails on both sides

10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage10x6ft Hot Dipped Galvanized Heavy Duty Hydraulic Tipping Tandem Trailer With Steel Cage
