Product Details
Condition: | New | Application: | Chemical, Commodity, Food, Medical | Packaging Type: | Bags |
Packaging Material: | Paper, Plastic | Automatic Grade: | Semi-Automatic | Driven Type: | Electric |
Voltage: | 220V/50HZ/3KVA | Power: | 2.2KW | Place of Origin: | Hubei, China |
Brand Name: | Dingxin | Model Number: | DSY-320L | Weight: | 750KG |
Dimension(L*W*H): | 1.2*0.8*2.3 m | Certification: | CE ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
DSY-520L Back Sealing Liquid Packing Machine/Packaging Machine/Packer
Uses:
Suitable for liquid or medium viscosity paste objects ,such as washing liquid, cleaning agents, fillings, spices, medicine, pesticides, dyes, pigments, etc.
Brief Introduction:
Liquid packing machine is equipped with computer-controlled system , integrating measuring, bag making, filling, sealing, batch number printing , cutting and etc.
Funtion & Characteristics:
1.The material contact is stainless steel,machine body is carbon steel(optional stainless steel).
2. Inverter and power switch are all imported with advanced technology.
3. Optional English or Chinese screen display, easy and simple operation.
4. Bag-making with précised technology enable the error less than ±o.5um.
5. Digital input of cutting position get more accuracy.
6. Packaging speed and length of bags can be set to some extent without further adjustment and parts changing.
7. Tailor made system for the liquid, cream, sace material, injection pump with leakproof device.
Packaging Material (Film):
Plastic film, paper, foil composite such as OPP/CPP, OPP/CE,MST/PE, MST/PE/PET/PE, Nylon and etc.
Advantages:
1. Pump quantitative metering, more accurate.
2. Simple structure, easy to disassemble and clean.
3. When packaging, pressing the button, it can automatically complete the operation, running fast and high efficiency.
4. Bag-making equipment can be changed according to specific requirement of customers and products so as to adjust the amount of packaging.
Technical parameters:
Model: | DSY-320L | DSY-420L | DSY-520L |
Measurement range(ml): | 100~800 | 150~1500 | 150~2000 |
Packing speed(bags/min): | 5~60 | 5~60 | 10~50 |
Bag width(mm): | 50~150 | 60~200 | 60~250 |
Bag length(mm): | 200 | 80~300 | 80~350 |
Film width(mm): | >320 | >420 | >520 |
Air pressure(mpa): | 0.65 | 0.65 | 0.65 |
Voltage: | 220V/50HZ/2.2KVA | 220V/50HZ/2.2KVA | 220V/50HZ/2.2KVA |
Net weight(kg): | 750 | 850 | 950 |
Dimensions(mm): | 1170×820×2285 | 1217×1015×2343 | 1488×1080×2543 |
Welcome to contact with me anytime, my friend!
