Greenhouse wheel Irrigation system for watering
- Qingdao/Shanghai
- T/T Credit Card PayPal
You May Like
-
2013 Hot Sale Travelling Irrigator , Hose reel irrigation systems
-
Rainwalker hose reel irrigator, removable irrigator JP75-300 with grider
-
Hose reel Irrigation Sprinkler 75-400TX, 75mm diameter and 400meters long, watering farm land
-
Heavy duty rotary tiller with CE for sale, Rotary hoe cultivator, Kubota tractor mounted rotary tiller
-
tractor backhoe attachment, 3PT hydraulic backhoe LW-6, LW-7, LW-8
-
Backhoe fit with 25-35HP Tractor, backhoe loader LW-6
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | HS | Model Number | JP65-200, JP65-300, JP75-250, JP75-300 | |
| Material | Other, Metal, Galvanized steel | Feature | flexible to move and storage | |
| Diameter | 65 inch | After-sales Service Provided | Overseas service center available |
Product Description
Specifications
Reel irrigation system1.galvanized steel frame
2.flexible to move and storage
3.0.5-0.8Mpa pressure
4.turbine recover
Hose reel irrigation system for watering farm land
Description
Hose reel irrigationsystem is mainly make up of the chassis, reel, PE pipe, water turbine, gearbox, driving the speed compensation
device and water composition.
The key components of water turbines, gearboxes, PE pipe and structural piece are in good or bad quality of the processing technology directly affects the effectiveness and use of the whole operational life.
Features
1.Irrigation machine is mainly composed of Frame, Reel,PE Tube, Water Turbine,Gearbox and Water Carriage.
2.With Charateristics of Simple and Compact Structure, Easy Operation and Moving, The irrigation machine can be operated by 1-2 persons.
3.High Efficiency and Large Irrigation Area. The Sprinkler can spray water in all directions.
4.Good irrigation quality and uniformity can be up to 85% above.
5.The Irrigation machine, with multi-functions, can be used for farmland irrigation, fruit and vegetable irrigation,pasture and sugarcane spray,power plant and port dedusting.
Hose Reel Irrigation System with Boom Technical Parameter:
Basic Unit | Model | PE-Pipe dia. | PE-pipeLength | Max. strip width | Water flow | Connection pressure | Nozzle No. *Dia. |
65TX | JP65-220 | 65 | 220 | 36 | 11.41-38.3 | 3.0-7.0 | 13*4.4-7.5 |
JP65-250 | 65 | 250 | 36 | 11.41-38.3 | 3.0-7.0 | ||
75TX | 65-340TX | 65 | 340 | 36 | 11.41-38.3 | 3.0-7.0 | |
75-300TX | 75 | 300 | 36 | 11.41-38.3 | 3.0-7.0 | ||
85TX | 75-350TX | 75 | 350 | 36 | 11.41-38.3 | 3.0-7.0 | |
75-400TX | 75 | 400 | 36 | 11.41-38.3 | 3.0-8.0 | ||
90-250TX | 90 | 250 | 36 | 11.41-38.3 | 3.0-8.0 | ||
90-300TX | 90 | 300 | 36 | 11.41-38.3 | 3.0-8.0 |
Boom Parameters:
Boom length | 26m |
Covering width | 36m |
Water flow | 13-60m3/h |
Pressure | 0.3-1.00Mpa |
Nozzle dia. | 4.4-7.5mm |
Working pressure | 0.10-0.20Mpa |
Sprinkling range | 1.0-5.5m |
Rainfall | 8-50mm |
The boom adopts stainless steel pipe, length is 26m.
Can use the AS26m boom cantilever type if the plant request small rainfall.
With the advantage of lower pressure, smaller water-drop, higher water distribution uniformity, small influence for wind.
Working photos:
Production photos:
JP50-150, JP65-200, JP65-300, JP75-300m, 75-400m, 90-300m are hot-selling now!
Welcome to visit us, if you are interested!
Contact us immediately for working video and quotation!
