Specifications
1. Whole hydraulic steering2. 120HP tractor
3. Germany LUK Single disk,independent operation,two-stag
Main Technical Data of 1204 farm wheeled Tractor | |
Engine | |
Engine type |
LRC 6105T51 |
Feature |
6 cylinder, water cooling, straight line, direct injection, natural aspiration |
Cylinder number |
6 |
Bore*stroke |
105*135 |
Rated power (kw) |
88.2 |
Rated revolution (r/min) |
2300 |
Fuel consumption (g/kw.h) |
≤240 |
Speed of max, torque (r/min) |
440 |
Engine oil conditions (g/kw.h) |
≤1.6 |
Lubricating method |
Pressure and splash lubricating |
Cooling method |
Forced circulating water cooling |
Clutch |
Two disk, LUK dry-type, independent operation two-stage |
Transmission box |
27 forward gear, 9 reverse gear (equipped with creeper) |
Brake assembly |
Foot controlled, hydraulic operating, single disk |
Constructional weight (kg) |
4200 |
Rated traction force (kn) |
28 |
Front wheel tire |
14.9-26 |
Rear wheel tire |
18.4-38 |
