LZ404 4WD 40HP Wheeled Farm Tractors With Sunshade
- Qingdao/Shanghai port
- T/T Credit Card PayPal
You May Like
-
LZ454 Wheeled Tractors With Cabin, Agricultural/compact Tractors
-
LZ700 2WD Farm Tractor, Two Wheeled
-
LZ804 Wheeled Agricultural Tractor, 4x4 Tractor, Big Tractor
-
LZ254 EPA Engine New Tractor
-
4WD Universal Farm Tractor; Wheeled Tractor 40HP, 45HP, 50HP And 55HP
-
Tractor, LZ404 40HP Farm Tractor, Cabin Farm Tractor
Product Details
| Condition | New | Type | Wheel Tractor | |
| By wheel | 4WD | Usage | Farm Tractor | |
| Certificate | EPA | Brand Name | LZ brand | |
| Model Number | LZ404 | Place of Origin | Shandong, China |
Product Description
Specifications
1.farm tractor 4 wheeled drive2.EPA diesel engine
3.Dual stage cluth,Shuttle gear,air break
4.power steering,double valv
Luzhong 404-504 Tractors Main Technical Specifications | |||||||
Model | LZ404 | LZ454 | LZ484 | LZ504 | |||
Type | 4WD Wheeled Type | ||||||
(mm)Dimensions of Tractor | Length (to front ballast) | 3835 | |||||
Width | 1620 | ||||||
Height (to the exhaust vent) | 2220 | 2135 | |||||
Tread | Front Wheel | 1280 | |||||
Rear Wheel | 1300 Fixed or 1200~1500 Adjusted | ||||||
Axle Base | 2030 | ||||||
Min.Ground Clearance | 325 | ||||||
Structure weight (kg) | 1665 | 1734 | |||||
Ballast weight | Front ballast | 140 | 168 | ||||
Rear ballast | 200 | 300 | |||||
Rated traction force (kg) | 1100 | 1130 | 1140 | 1150 | |||
EPA Engine | Model | 3105/490 | 495 | 495/498 | 498/4100 | ||
Type | Vertical,4-Cylinder,Water Cooled and 4-stroke | ||||||
Rated Power(kw) | 29.4 | 33 | 35.2 | 36.7 | |||
Rated speed (r/min) | 2400 | ||||||
Fuel | Diesel | ||||||
Tyre | Front Wheel | 8.3-20 | |||||
Rear Wheel | 12.4-28 | ||||||
Clutch | Dual-stage clutch | ||||||
Steering | power steering | ||||||
Transmission Type | 8+8 with shuttle gearshift or (8+4)×2 with creeper shift | ||||||
Suspension Type | 3-point links | ||||||
PTO | Type and Rev | Semi-independent Type 540/1000 | |||||
Spline Size | F35 Rectangle Spline with 6 teeth | ||||||
|
|
|
|
|
|
| |
Structure and specification are subject to change without notice. |
|
| |||||
