LZ304,30HP, 4WD Mini Garden Tractors Fit With 4in1 Front End Loader, Mini Garden Tractor Loader

LZ304,30HP, 4WD Mini Garden Tractors Fit With 4in1 Front End Loader, Mini Garden Tractor Loader thumbnail-1
LZ304,30HP, 4WD Mini Garden Tractors Fit With 4in1 Front End Loader, Mini Garden Tractor Loader photo-1
US$ 1,600 - 4,500 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Gooler International Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao / Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Certificate Other
Brand Name LZ brand
Model Number LZ304, TZ03D
Place of Origin Shandong, China

Specifications

1. Mini garden tractor 4WD
2. fit with loader,backhoe
3. pallet fork,slasher mowe
4. Dual stage cluth,Shuttle gear,air break.

 LZ304,30HP, 4WD mini garden tractors fit with 4in1 front end loader, mini garden tractor loaderLZ304,30HP, 4WD mini garden tractors fit with 4in1 front end loader, mini garden tractor loaderLZ304,30HP, 4WD mini garden tractors fit with 4in1 front end loader, mini garden tractor loaderLZ304,30HP, 4WD mini garden tractors fit with 4in1 front end loader, mini garden tractor loaderLZ304,30HP, 4WD mini garden tractors fit with 4in1 front end loader, mini garden tractor loader



LZ254-304 Tractors Main Techical Specifications




Model

LZ254

LZ284

LZ304



Type

4WD    Wheeled Type



(mm)Dimensions of Tractor

Length (to front ballast)

3030



Width

1470



Height (to the exhaust vent)

1900



Tread

Front Wheel

1215 Fixed or 1150~1215 Adjusted




Rear Wheel

1300 Fixed or 1300~1350 Adjusted




Axle Base

1710



Min.Ground Clearance

347.5




Structure weight (kg)

1130



Ballast weight
(kg)

Front ballast

56



Rear ballast

112



Rated traction force (kg)

551

591

663



EPA Engine

Model

385

385

390/485



Type

Vertical,3-Cylinder,Water Cooled and 4-stroke



Rated Power(kw)

18.4

20.6

22




Rated speed (r/min)

2400




Fuel

Diesel



Tyre

Front Wheel

6.00-14



Rear Wheel

9.5-24



Clutch

Dual-stage clutch



Steering

power steering



Transmission Type

8+2 or 8+8 with shuttle gearshift or 16+4 with creeper shift



Suspension Type

3-point links




PTO

Type and Rev

Semi-independent Type 540/1000




Spline Size

F35 Rectangle Spline with 6 teeth




Structure and specification are subject to change without notice.
