Tractor, High Quality DQ554 Farm Cabin Tractor, Wheeled Tractor in Agriculture, 55HP, 4x4, Luxury Cabin
Specifications
1.Tractor,40hp/55HP,4WD2. EPA engine, 4 cylinder
3.hydraulic steering, luxury cabin
4.shuttle gear, 2 way hydraulic valve
Introduction of High quality Farm tractor, DQ404, 40HP, 4WD with rops, sunshade
Advantages and Characteristics of 40/55 series tractor:
1. Equipped with famous brand engine, with good performance, low fuel consumption and high economic efficiency.
2. Streamlined appearance with novel design.
3. 6 or 8 spline PTO( Power Take Off).
4. Rotation speed of PTO: 540/760r/min.
5. Can be equipped with ROPS, canopy, cabin, front/rear ballast, loader, and so on;
6. Tire size: front tire 8.3-20, rear tire 12.4-28.
7.Can match implements such as Front end loader, Backhoe, Plough, Harrow, Trailer, snow blower, and so on.
1. Farm tractor 4 wheeled drive
2. 4-cylinder EPA diesel engine
3. Dual stage cluth,Shuttle gear, luxury chair etc.
4. 3point linkage with plough, harrow, mower, loader, backhoe, digger, trailer etc.
Main Technical Data of Farm Tractor DQ404/DQ554
DQ40-55 SERIES SPECIFICATION | ||
Model |
DQ404 |
DQ554 |
Drive type |
4x4 |
4x4 |
Engine | ||
Type of engine |
Xinchai 4-Cylinder |
|
Capacity of fuel tank(L) |
38L |
|
Engine power at rated speed |
29.4KW |
40.5KW |
Rated speed (r/min) |
2400 |
|
Transmission | ||
Clutch |
dry,dual-stage type |
|
PTO speed |
Double PTO 540/760rpm |
|
Gear shift |
8F+4R/8F+8R(Optional) |
|
Hydraulic system | ||
Hydraulic output valve |
2-Way (optional) |
|
Three point linkage | ||
Category of 3-point link |
rear, category I |
|
Lifting force(at point of 610mm)KN |
11 |
12 |
Technical parameter | ||
Overal size(LxWxH)mm |
3513x1750x2130 |
|
Wheel base(mm) |
1924 |
2040 |
The smallest clearance(mm) |
325 |
325 |
Front tire |
8.3-20 |
8.3-20 |
Rear tire |
12.4-28/14.9-24(optional) |
|
