1BQX Series Compact Disc Harrow Farm Equipments for Small Tractor Usage

1BQX Series Compact Disc Harrow Farm Equipments for Small Tractor Usage photo-1
US$ 480 - 680 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Farm Cultivator
Power Type:
Other, Tractor
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Farm Cultivator
Power Type Other, Tractor
Power(W) 9kw-37kw
Certification BV, ISO9001
Warranty 12 months
Use cultivation
Place of Origin Shandong, China
Brand Name CLOUD PILLAR
Model Number 1BQX
Weight 180kg
Dimension(L*W*H) 1.8*1.5*0.8m
After-sales Service Provided Engineers available to service machinery overseas

Product name: 1BQX series of light-duty mounted disc harrow





Uses:

Disc harrows are primarily used to chop up soil that has been recently plowed to eliminate

clumps and loosen the soil if it has been packed. They are also used to chop up old crops,

such as cornstalks, to make the land easier to plow and to eliminate clogging in the plowing process.





Specifications:

Model: 1BQX-1.1, 1BQX-1.3, 1BQX-1.5, 1BQX-1.7, 1BQX-1.9, 1BQX-2.3

Working width: 1100-2300mm

Working depth: 120mm

Quantity of disc: 12, 14, 16, 18, 20, 24

Disc diameter: 460mm

Overall weigh: 200-360kg

Matched power: 12-50hp

Linkage: standard three point mounted

Color: yellow,red,blue,green or customize



Pictures:

 1BQX series compact disc harrow farm equipments for small tractor usage



1BQX series compact disc harrow farm equipments for small tractor usage



1BQX series compact disc harrow farm equipments for small tractor usage



Technique parameter:

Model

Unit

1BQX-1.1

1BQX-1.3

1BQX-1.5

1BQX-1.7

1BQX-1.9

1BQX-2.3

Working width

m

1.1

1.3

1.5

1.7

1.9

2.3

Working depth

mm

120

Q’ty of disc



12

14

16

18

20

24

Disc diameter

mm

460

460

460

460

460

460

Total weight

kg

200

220

240

260

310

360

Matched power

hp

12

15

25

30~35

35~45

50

Linkage



Standard three-point mounted







Package and Shipment

1BQX series compact disc harrow farm equipments for small tractor usage



1BQX series compact disc harrow farm equipments for small tractor usage



We also have more other farm equipments, please do not hesitate to contact us for more information.
