New Mini Skid Steer Loader With Auger
- Qingdao
- T/T L/C D/P D/A Money Gram
You May Like
Product Details
| Condition | New | Brand Name | CP | |
| Model Number | JC45 | Place of Origin | Shandong, China | |
| Type | Skid Steer Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 3200x1740x2030mm | Rated Load | 700kg | |
| Certification | CE | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
mini skid steer loader with augerCapacity700kg;Tipping load1400kg
Bucket capacity:0.36-0.45cbm
Weight2600kg
Tyre model:10.0
mini skid steer loader with auger
Features:
1)maneuver in tight spaces, turn within its own length
2) a broad product line, innovative designs, and unsurpassed range of job-matched attachments.
3)Excellent reach & lift height for truck loading (vertical path).
4)more than 20 series attachments for option: pallet fork, swing blade, utilityfork grapple, asphalt cutter, backhoe, hydraulic hammer, 4 in 1 bucket, auger,cultivator, and tooth bucket etc
5)uses the double rising and falling arms with tile auto-leveling system to make tile lifting and falling safety and quickly
6)attachment can be used with bobcat type skid loader
7)world famous hydraulic systems from America and Italy
8)famous brand engine with EPA or EC stage ii from abroad and domestic
9) CE and ISO 9001 certificated
10)versatility, maneuverability and reliability
Specification as follow:
Rated operating capacity(kg) | 700 | |
Tipping load(kg) | 1400 | |
Bucket capacity(m 3 ) | 0.36-0.45 | |
Operating weight(kg) | 2600 | |
Max. travel speed(km/h) | 12 | |
Hydraulic pump flow(L/min) | 62.5 | |
Fuel tank capacity(L) | 50 | |
Tires | 10.0/75-15.3 | |
Overall dimensions(mm) | 3200— 1740— 2030 | |
Dimensions: | ||
Height at maximum extension(mm) | 3670 | |
Height to bucket hinge pin(mm) | 2900 | |
Width with bucket(mm) | 1740 | |
Track width(mm) | 1450 | |
Wheelbase(mm) | 991 | |
Ground clearance(mm) | 185 | |
Dump angle | 40° | |
Dumping height(mm) | 2310 | |
Maximum reach(mm) | 710 | |
Engine: | ||
Maker/Model | XINCHAI 490BPG | |
Net power | 50hp/2650rpm | |
Type | 4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine | |
Displacement(L) | 2.54 | |
Standard: | ||
(1). Open-type operator cab | ||
(2). Hand control system(Mechanical type) | ||
(3). Standard bucket | ||
(4). Auxiliary hydraulic couplers | ||
