Specifications
cheap back loader for salewheel loader zl30
wheel loader 5000kg
zl60 wheel loader
5tons wheel loader
WZ30-25 cummins engine cheap back loader for sale ,
adopting European technology,
is featured by strong power, pilot control, comfortable ,operation,
WZ30-25 technological parameters
Overall Dimension | |
1 Length *Width* Height |
5900*2200*3769(mm) |
2 Cab roof height |
2900(mm) |
3 Wheel base |
2250(mm) |
4 Track |
1640(mm) |
5 Min. ground clearance |
300(mm) |
Main Technical Specification | |
1 system pressure | |
load hydraulic system |
18Mpa |
dig hydraulic system |
20Mpa |
steering hydraulic system |
12Mpa |
2 system flow |
120L/min |
3 four-wheel drive , whole hydraulic system | |
4 total operating weight |
7600kg |
5 maximum speed |
22Km/h |
6 maximum gradient capacity |
30° |
1 loading bucket capacity |
1m3 |
2 rated loading |
2500KG |
3 maximum articulated height of bucket |
3400 mm |
4 bucket discharge height |
2795(mm) |
5 bucket discharge distance |
1048(mm) |
6 loading lift capacity |
25KN |
7 bucket hydraulic translation function |
yes |
8 bucket lift time |
6.8s |
9 bucket lower time |
2.5s |
10 bucket discharge time |
1.2s |
11 maximum tractive force |
39KN |
12 maximum breakout force |
38KN |
1 backacter bucket capacity |
0.3m3 |
2 backacter discharge height |
3878(mm) |
3 maximum digging depth |
4080(mm) |
4 maximum digging radius |
5688(mm) |
5 bucket slewing angle |
190° |
6 bucket digging capacity |
46KN |
7 bucket stick digging capacity |
31KN |
Diesel engine | |
1 model |
Cummins 4BTA3.9-C100 |
2 type |
turbocharging four-stroke |
3 rated power |
55KW/74HP |
4 rated speed |
2200 r/min |
4 cylinder –internal diameter |
4-108 |
5 maximum torque |
261.7N.M/1800R/MIN |
6 minimum fuel consumption |
216 g/kw.h |
7 displacement |
4.4L |
Transmission system | |
1 model of hydraulic pump |
fixed shaft power shift transmission |
2 gear shift |
2forward shift 2 reverse shift |
3 torque |
YJ-280 |
4 drive pump |
CDXaf3016-IL |
5 flow |
16ml/r |
6 work pump |
CBGj2063 |
7 flow |
63ml/r |
Steering system | |
1 type |
articulated hydraulic steering |
2 model of steering control valve |
BZZ5-250 |
3 model of turning control valve |
YSF25S-00 |
4 steering angle |
36±1°left or right 36±1° |
5 minimum turning radius |
5018(mm) |
Axles | |
1 main transmission type |
single reduction |
2 wheel reduction type |
wheel reduction |
Wheel | |
1 tire size |
16/70-20 |
2 front wheel pressure |
0.22Mpa |
3 rear wheel pressure |
0.20Mpa |
4 service braking |
air over hydraulic disc on 4 wheels |
5 parking brake |
manual parking brake |
Refill Capacity | |
1 fuel tank |
70L |
2 transmission |
25L |
3 front axle |
9KG |
4 rear axle |
9KG |
5 hydraulic tank |
140L |
