Home > Sporting Goods & Recreation > Pet Supplies > Pet Carrier > TA NO.1 Factory Floating Fish Feed Making Machine

TA NO.1 Factory Floating Fish Feed Making Machine

Hebei Dingtuo Machinery And Equipment Co., Ltd.

TA NO.1 Factory Floating Fish Feed Making Machine thumbnail-2

TA NO.1 Factory Floating Fish Feed Making Machine thumbnail-3

TA NO.1 Factory Floating Fish Feed Making Machine thumbnail-4

TA NO.1 Factory Floating Fish Feed Making Machine thumbnail-5

TA NO.1 Factory Floating Fish Feed Making Machine photo-1

TA NO.1 Factory Floating Fish Feed Making Machine photo-2

TA NO.1 Factory Floating Fish Feed Making Machine photo-3

TA NO.1 Factory Floating Fish Feed Making Machine photo-4

TA NO.1 Factory Floating Fish Feed Making Machine photo-5

US$ 180 - 1,800 MOQ: 1 Set

Key Specifications

Get Latest Price

Use:

Chicken

Type:

Pellet machine

Material:

Galvanized Wire

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

XINGANG SHANGHAI QINGDAO GUANGZHOU NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Use Chicken

Type Pellet machine

Material Galvanized Wire

Place of Origin Hebei, China

Brand Name DT

Model Number DT-Floating fish feed machine

TA NO.1 factory floating fish feed making machine

Related Machine you may need, please contact us !

Feed mill ( mixing and grinding)

For animals

Pellet machine

For wood or animal feed

Floating fish feed machine

Application
Powder raw materials ,amino acid, soybean meal,grain, straw, green feed and so on.

the machine process the raw materials as the floating type feed for the fishery ,poultry ,pet ornamental fishes and so on.

Structure

Feeding device , feeding motor , heater band ,cutter , main motor , control cabinet

Working principle

Raw materials under high temperature (120-150 degrees Celsius) and high pressure (3.0-10Mpa), through different die holes , the material is extruded from the the die holes of the moulds, into the atmosphere, pressure and temperature drop quickly , make the volume expands rapidly, the moisture evaporate rapidly , solidfication and became puffed feed.

Specification

1) Floating fish food diameter: 1.0-12mm

2) Pet feed: triangle type, flower type, bone type and so on

3) Mould quantity : 3 moulds freely (including the mould on the machine)

4) Voltage: Electric control cabinet is connected to 380V ,three wires, and a zero line (main motor 380V 50Hz , three-phase power, feeding and cutting motor 220V 50Hz, two-phase)

Type	Output/H (KG/H)	Main motor power (KW)	Cutter power (KW)	Feeding device power (KW)	Size (MM)	Weight (KG)
DT-40	30-40	5.5	0.4	0.4	140011001200	240
DT-80	60-80	11	0.4	0.4	145011101250	320
DT-150	100-150	15	0.4	0.4	147011201250	350
DT-200	180-200	18.5	0.4	0.6	175014001270	590
DT-250	200-250	22	0.6	0.6	190014501300	720
DT-400	350-400	37	0.8	0.6	200014501350	950

Delivery

Directly loading in container

Visit my website

Welcome visit my website, you will get the followed information

1) the step to building chicken house

2) 3D showing cage & equipment layout

3) Automatic cage and equipment project design

4) African project & african farms ' difference with normal one

5) Cage & equipment production steps and lines

...

Connection

Service

Our relationships with you does not end once we make the sale, or once we get your poultry equipment and rearing system in operation. We back up our commitment to quality with service over the entire life cycle of your equipment.

1. Delivery Time

Dingtuo have a large number of products in stock throughout the year. So we promise in time delivery. The shortest preparation time before delivery is 3 days.

2. Accessories

As for quick wear parts like plastic parts, we will perform reliable package and send extra parts to ensure that damage of some part will not influence the normal use of the whole poultry production system.

3. Installation

We offer customers installation guidance through combination of pictures, texts and videos. For some poultry equipment, we also appoint technicians to conduct on-site installation guiding.

4. Mutual Benefit

If the products of our distributors are unmarketable due to the influence by market factors,we will seek customers in the same market or near market who are in need of the products to help the distributors to handle unsalable products.

5. Trouble Shooting

If the equipment has problems in use, we will appoint technicians to carry out trouble shooting in the shortest time.

6. Warranty

Warranty time for plastic parts are 5 years. Rusted cage nets can be replaced for free within 10 years.Replacement parts will be freely delivered to your place.Machine are 5 years to 10 years replaced as different types .
