1500L Fermentation Tank

1500L Fermentation Tank thumbnail-1
1500L Fermentation Tank thumbnail-2
1500L Fermentation Tank photo-1
1500L Fermentation Tank photo-2
US$ 50,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
NM
Contact Supplier Request Quote Chat Now
Zhenjiang Norman Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name NM
Model Number APJ1500L
Processing Types Alcohol
Voltage 220V/380V
Power(W) 4KW
Dimension(L*W*H) User Requirements
Weight 500kg-80ton
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

1500L Fermentation Tank

Product Description:

NO. Parameter Name Technical Indicator
1 PH Control
  1. On-line check and measure, and digitization fully automatic control;
  2. PID control 2 Peristaltic pumps for acid and base feeding;
  3. Measure range 0~14pH, control range 2~12pH, measure precision 0.01pH, control precision ±0.02pH;
  4. It has auto upper and lower limit alarm function.
2 DO Control
  1. On-line check and measure, DO and rotate speed gang control;
  2. Range 0-100% or 0-150%, precision ±0.1% or 1%;
  3. Hamilton sensor and cascade control with agitation speed;
  4. High temperature in place sterilization, 121ºC for 30 minutes;
  5. It has auto upper and lower limit alarm function.
3 Foam Control
  1. Automatically control;
  2. Control precision: 10-100000Ω;
  3. Antifoam-meter with cascade control of 1 Peristaltic pump;
  4. It has auto alarm function.
4 Feed Control
  1. Manually control;
5 Temp.Control
  1. On-line check and measure, PID intelligent control, can be set according to the temperature required for the fermenting process ;
  2. Measure range 0~150ºC, control range 15ºC~+45ºC, measure precision 0.1ºC, control precision ±0.2ºC
  3. Some accessories: PT100 temperature sensor from Japan, stainless steel electrode sheath and chiller (The fermenting process is a cooling process).
6 Rotate Speed Control
  1. Fully automatic control settings, with automatic alarm function;
  2. Range 40-500rpm, precision ±1%;
  3. It is mechanical agitator, vertical impeller.
7 Sterilization      1. SIP Manually control
8 Air Flow and Pressure
  1. Checking by diaphragm pressure gauge, manually control, range 0-0.4Mpa.
  2. Manually control intake air flow with glass rotor meter, 0.5-2VVM;
  3. check valve is added on the pipeline;
 Our Certification:
1500L Fermentation Tank
 About Us:
1500L Fermentation Tank1500L Fermentation Tank1500L Fermentation Tank1500L Fermentation Tank
Our Advantage and Why Choose us:
1.We have our own factory:
  1) We have more than 15 years extensive experience of manufacturing fermenter,/ bioreactor;
  2) We have the latest high-tech equipment;
  3) We have a strong design team and can do the design, production, installation, debugging
       integration. Large scale of production, cooperation with local universities;
  4) We have professional and strong after sale service team, best service for you.
2. Low price: We try our best to make sure our prices are the lowest anywhere, factory lowest
   price for you. We are proud to help you save money on the products you want.
3. Good quality and we passed "special equipment installation modification maintenance license"
   (pressure pipe installation) GC class GC3 level and"special equipment manufacturing license"
   (pressure vessels) D1, D2 kind certification: We have strict quality control system.We have good
   reputation in the market. Our long time customers always said our quality is very good.
4. On-time delivery & cheap shipping cost and best service team: We have more than 10 years
   export experience all over the world.

We warmly welcome friends from both home and abroad and we are willing to be your loyal friend, providing with excellent service.
