water ingress alarm system

Specifications

water ingress alarm system
1.certificate:ABS,BV,CCS,etc.
2.material:stainless steel
3.sensor:pressure
4.low cost

water ingress alarm system



The product can satisfy relevant marine standards as following:

Hold, ballast and dry space water level detectors (Chapter XII, Regulation 12(Resolution MSC,134(76))) Performance Standards for water level detectors on Bulk Carriers(Resolution MSC,145(77))

IACS UI SC180

The product is admitted bu classification societies as following:

ABS, BV, CCS, CR, DNV, GL, KR, LRS, NK, RS





SAVE YOUR INSTALLATION COST, EMC REACHES MILIARY STANDARD

1. The alarm control panel has advantages including artistic externality, compact configuration, convenient installation, easy-to-master operation. The alarm panel is installed on main console by flush type, it can be installed on the wheel house very easily.

2. Less cables are needed for installation and lower cost for the whole system,which only needs one  4*1mm² cable from wheel house to the fore bosun store.The detector cable is connected to the 4*1mm² cable in parallel via safety barrier,to provide powder to detector and do data transfer.

3. The data are transfered in digital format with strong nsti-jamming performance and high stability.

4. Data interface is designed in RS232/422, VC/VO formats, and can be connected to the VDR conveniently.

5. Made of stainless steel to insure longer lifetime, the safety barrier is installed on the main deck.

6. With excellent performance, the detectors  are designed with safe and reliable installation method and

easy approaching for function tests.
