Marine/boat Hydraulic Steering Gear for Sale

Name: Marine/boat Hydraulic Steering Gear for Sale
Brand: ZJNM
SKU: 138989295
Availability: InStock

US$ 500 - 1,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

ZJNM

Model Number:

Oscillating Hydraulic

Zhenjiang Norman Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name ZJNM

Model Number Oscillating Hydraulic

Part Piston

Marine/boat hydraulic steering gear for Sale

Specification

1.Certificates: CCS, DNV,ABS,GL,LR,BV,RINA,NK,KR and other classification societies

2.Rated Torque: 3.5-1500KN.m

3.Park: Deck Equipment

4.Control Ways: Electronic, Pump or Manual

5.Type: Hydraulic

Specification	Norminal torpue	Steering angle	Steering time (S/65°)	Duty (mm)
3.5-8.5kN·m Hydraulic Oscillating Cylinder Steering Gear	3.5/8.5	±35	12,20,28	Ⅰ,Ⅱ
8.5-12.5kN·m Hydraulic Oscillating Cylinder Steering Gear	8.5/12.5	±35	12,20,28	Ⅰ,Ⅱ
10/16kN·m Oscillating Cylinder Steering Gear	10/16	±35	12,20,28	Ⅰ,Ⅱ
10/16kN·m Hydraulic Recirculating Type Steering Gear	10/16	±35	12,20,28	Ⅰ,Ⅱ
25kN·m Oscillating Cylinder Steering Gear	25	±35	12,20,28	Ⅰ,Ⅱ,Ⅲ
25/40kN·m Hydraulic Recirculating Type Steering Gear	25/40	±35	12,20,28	Ⅰ,Ⅱ,Ⅲ
40kN·m Oscillating Cylinder Steering Gear	40	±35	12,20,28	Ⅰ,Ⅱ,Ⅲ
50kN·m Hydraulic Recirculating Type Steering Gear	50	±35	12,20,28	Ⅰ,Ⅱ,Ⅲ
Dych-50/20-DK-2D Electro-Y-Type Hydraulic Steering Gear	50	±35	12	Ⅰ,Ⅱ,Ⅲ
63kN·m Hydraulic Oscillating Cylinder Steering Gear	63	±35	12,20,28	Ⅰ,Ⅱ,Ⅲ
63/100kN·m Hydraulic Recirculating Type Steering Gear	63/100	±35	12,20,28	Ⅰ,Ⅱ,
160kN·m Electro-Hydraulic Steering Gear	160	±35	12,20,28	Ⅰ,Ⅱ,Ⅲ
250kN·m Electro-Hydraulic Steering Gear	250	±35	28	Ⅰ,Ⅱ,Ⅲ
400kN·m Electro-Hydraulic Steering Gear	400	±35	28	Ⅰ,Ⅱ,Ⅲ
750kN·m Hydraulic Recirculating Type Steering Gear	750	±35	28	Ⅰ,Ⅱ,Ⅲ
1000kN·m Hydraulic Recirculating Type Steering Gear	1000	±35	28	Ⅰ,Ⅱ,Ⅲ
1250kN·m Hydraulic Recirculating Type Steering Gear	1250	±35	28	Ⅰ,Ⅱ,Ⅲ
1500kN·m Hydraulic Recirculating Type Steering Gear	1500	±35	28	Ⅰ,Ⅱ,Ⅲ
