Worm Gearbox Reducer

Specifications

worm gearbox reducer have been designed for different transmission .The power is transmitted from the motor to sun gearboxes. The sun gearbox drives three Planetary Gearboxes, which are contained within an internal toothed ring gearbox. The Planetary Gearboxes are mounted on the planetary carrier. The planetary carrier is part output shaft. So when the sun gearbox rotates, it drives the three Planetary Gearboxes inside the ring gearboxes. As Planetary Gearbox rotate with carries and automatically the highest torque and stiffness for a given envelope. The other significant advantages are simple and efficient lubrication and a balanced system at high speeds. The balanced planetary kinematics and the associated load sharing make the planetary-type gearbox truly ideal for servo applications. Modular concept, allows us to arrange short delivery time for gearboxes with a constantly high standard of quality as per your applications of reducer for motors, Let our team of engineers work for you.

See the below features:

Output torque Range: 1000 to 450000 Nm

Transmissible Mechanical Power: up to 450 kW

Gear Ratios: 3 to 9000

Gear Unit Versions: In line

Right angle (with a spiral bevel gear set)

Output Configuration: Foot and flange mounted

Output shaft: solid with key, spline, spline hollow,

Hollow with shrink disc

Input Configurations

Flanged axial piston hydraulic motors

Hydraulic orbit motors

IEC and Nema motor adaptors

Solid input shaft

Hydraulic Brake: Hydraulically released parking brake on request

Electric Brake: DC and AC type

You are welcome to send us detail enquiry by e-mail or fax.
