5XFJ-5 High Quality Seed Grading Machine
Application
The Seed Grading machine is used for grading the seeds in different size according to width or thickness of seeds by 2-6 sieve layers with different sieve mesh. The Machine's sieves could be changed so that the machine can sieve every kind of material. Two vibro motor is using at the machine for vibration. Motor vibration weighths settings could be change.
Working Principle
Normally, the 5XFJ-5 High quality grain seed grader is three floored. From raw material depot control cover opens and raw materials unstucks from big matters at the first sieving floor. At the second floor, raw material unstucks from dust, bran and the little matter. Three unloading cover is located at the machine. From first cover bigger matters, from second cover bran, from third cover very little matters and dust could be taken away.
Features
The 5XFJ series seed grading machine include a bucket elevator, and it drive by two vibratory motors that lead to long life cycle and no maintenance cost. It can grade all types grain & seed, just by changing the inside sieve meshes conveniently.
Specifications
Model No. |
Capacity (KG/H) |
Power (KW) |
Dimensions (MM) |
Weight (KG) |
Available Sieve Layer |
5XFJ-3 |
3000 |
1.25 |
2500*1700*2200 |
700 |
2-3 |
5XFJ-5 |
5000 |
1.4 |
3500*1900*2600 |
900 |
2-4 |
5XFJ-7.5 |
7500 |
1.85 |
3900*2150*2800 |
1200 |
3-5 |
5XFJ-10 |
10000 |
2.25 |
3900*2300*2800 |
1400 |
3-6 |
5XFJ-20 |
20000 |
3.7 |
3900*2600*3000 |
