grain seed calibration machine
Application
The Seed Grader is used for grading the seeds in different size according to width or thickness of seeds by 2-6 sieve layers with different sieve mesh. The Machine's sieves could be changed so that the machine can sieve every kind of material. Two vibro motor is using at the machine for vibration. Motor vibration weighths settings could be change.
Working Principle
Normally, the 5XFJ-5 High quality grain seed grader is three floored. From raw material depot control cover opens and raw materials unstucks from big matters at the first sieving floor. At the second floor, raw material unstucks from dust, bran and the little matter. Three unloading cover is located at the machine. From first cover bigger matters, from second cover bran, from third cover very little matters and dust could be taken away.
Features
The 5XFJ series seed grading machine include a bucket elevator, and it drive by two vibratory motors that lead to long life cycle and no maintenance cost. It can grade all types grain & seed, just by changing the inside sieve meshes conveniently.
Specifications
Model No. |
Capacity (KG/H) |
Power (KW) |
Dimensions (MM) |
Weight (KG) |
Available Sieve Layer |
5XFJ-3 |
3000 |
1.25 |
2500*1700*2200 |
700 |
2-3 |
5XFJ-5 |
5000 |
1.4 |
3500*1900*2600 |
900 |
2-4 |
5XFJ-7.5 |
7500 |
1.85 |
3900*2150*2800 |
1200 |
3-5 |
5XFJ-10 |
10000 |
2.25 |
3900*2300*2800 |
1400 |
3-6 |
5XFJ-20 |
20000 |
3.7 |
3900*2600*3000 |
Other machine may you are interested
1. Seed cleaner & grader : remove dust,light impurity by air suction,remove big and small impurity by sieve grading.
2. Destoner: use to remove stones and other heavy impurity as glass, metalic pieces from grain seeds.
3. Gravity Separator: used to remove the partially eaten,immature, damaged, sick ones, especially for seed separation.
Synmec also built different processing plants worldwide.
Barley Seed Processing Plant in Australia
Q1. Which machine is suitable for my grain/seed?
Plese inform us your raw material condition, our engineer will recommend suitable machine to you.
Q2.How can I know the machine performance?
We have machine test video for your reference.
Q3.What is your company after-sales service?
Everey machine enjoy 1 year warranty. We will offer fully guidance on operation questions. Any parts problem happended during the warranty year, our company will offer you spares. After warranty, we help clients solve problem patiently as our repsonsibility.
Any question or idea feel free to contact me by following contact details.
Contact person: Ms.Joyce Liu
Contact e-mail: joyce at
Tell/Fax No.: 0086-311-67663887
Mobile No.: 0086-13180064751 Whatsapp:008613180064751
Skype: synmec-joyce QQ: 1523721875
Trade Manager: cn220238132
Website:
Hebei Ruixue Grain Selecting Machinery Co., Ltd was established in 2002. We are professional grain seed processing machine manufacturer. Seed cleaner, destoner, gravity seprator, etc are all our competitive machines. In 2010 we founded SYNMEC, as an International brand and works on international marekt. Our professional teams are motivated to provide efficient solutions to clients over the world. Up to Jan 2016, we exported machines over 100 countries and building 58 sets grain seed processing plants wordlwide.Sincerely wish to cooperate with you.
