Grain Seed Cleaner of Blow Type (2017 the hottest)

FOB Price

USD $14,000 - $25,000 / Set

1 Set(Min.Order)

Product Details

Type:	Grain Seed Cleaner	Use:	For cleaning wheat, maize, beans(seed)	Certification:	ISO9001:2008
Place of Origin:	Hebei, China	Brand Name:	SYNMEC	Model Number:	5X-12
Condition:	New	After-sales Service Provided:	Engineers available to service machinery overseas

Grain Seed Cleaner

INTRODUCTION of seed cleaner

The 5X series wheat seed cleaner cum grader is a universal machine well suited for pre- and fine cleaning many different species of grain and seeds.

The standard design of the machine is provided with both pre and after suction units.

Quick screen changing from pre-cleaning into fine cleaning by the operator serves to optimize the cleaning tasks.

The 5X series wheat seed cleaner cum grader is a very competitive machine, both as regards price and capacity as well as function and operation.

The technology of the machine is thoroughly tested, which can be documented by many references all over the world.

SPECIFICATION of wheat seed cleaner

Model	5X-5	5X-12
Dimension(L×W×H)	3200×1920×3600 mm	3790×1940×4060 mm
Overall weight	3250 kg	3600 kg
Rated capacity	5 t/h	12 t/h
Overall air volume	8200 m3	12520 m3
External air blower	4-72N0-6A, 7.5 kW	4-79N0-6A, 11kw
Vibration sieve motor(gear motor)	2.2 kW	2.2 kW
Back lifting system motor	3.0 kW	3.0 kW
Feeding motor	1.5 kW	1.5kw
Total Power	6.7 kW	6.7kw
Air Blower Type	centrifuge air blower
Top air blower Rotary speed	4-79NO6A,1400 r/min
Back lifting air blower Rotary speed	100~1000 r/min
Screen Type	piercing screen
Screen Dimension (L×W)	800×1250 mm
Frequency	300(80~400) times/min
Amplitude	30 mm
Layers and number	4 layers,7 pieces	5 layers,15 pieces
