Rice Destoning Machine
Introduction of TQSF-100 Rice Destoning Machine:
TQSF rice destoning machine is applied for efficient separation of stones and pebbles, glass, and other high-density impurities from the stream of grain, according to the difference in specific weight.
Features of TQSF-100 Rice Destoning Machine:
TQSF-100 rice Destoning machine is suction type destoner, but it has two sieve layers, the first sieve layer to remove out some large impurities such as straws, and the second sieve layer is used for remove out stones.
Working Principle of TQSF-100 Rice Destoning Machine:
The sieve box normally equipped with two-layer sieves, and its vibration depend on two vibratory motors.
The grain feed in with an elevator, and then the grain stream fluided by the vibration of the screen and air suction from bottom to top. The light particles collect at the top, and the heavy ones including the stones at the bottom.
The lower layer with the heavy particles flows upward and transport to the stone outlet. The stone-free grain streams on the two screens float on cushions of air, flowing slowly toward the grain outlet.
To achieve the optimum degree of separation, the inclination of the screens, the air volume and final separation can be adjusted accordingly.
Model |
Capacity (tone/hour) |
Power (kw) |
Weight (kg) |
Dimension (L×W×H)mm |
Remarks |
5XQS-3 Destoner |
3 |
4.75 |
600 |
2200×1200×1600 |
Blowing type |
5XQS-5 Destoner |
5 |
7 |
700 |
2500×1660×1600 |
Blowing type |
QSX-85 Destoner |
5 |
3.55 |
400 |
1300×1500×3200 |
Suction type |
TQSF-60 Destoner |
5 |
3.5 |
320 |
1450×876×1800 |
Suction type |
TQSF-80 Destoner |
7.5 |
3.5 |
400 |
1450×1046×1800 |
Suction type |
TQSF-100 Destoner |
10 |
3.5 |
480 |
1450×1246×1920 |
Suction type |
5XQS Series Destoner
QSX-85 Destoner
We have professional world trading team with rich world trading experience, provide full English user manual, Video using
instruction, Oversea machine assembly and On-site training.
1. Q Are you factory or trading company?
A We are professional manufacturer for seed processing machinery and also a international trading company
2. Q What is your minimum order quantity?
A 1 Set
3. Q What are your payment terms for new customers?
A T/T, L/C, Money Gram, West Union, Paypal etc
4. Q How long will it take for my products to arrive me?
A Usually by sea, 20 days to 50 days depend on which country you are in.
5. Q How can I visit your factory?
A1. From Guangzhou Baiyun International Airport to Shijiazhuang international airport (2.5hours) , then to our factory by car (1hour)
A2. From Beijing West Railway Station to Shijiazhuang Railway Station by high-speed train(1.5 hours), then to our factory by car (45minutes)
A3. From Hongkong International airport to Shijiazhuang international airport (4.5hours), then to our factory by car (1hour)
