Specifications
nutritional baby rice powder machine1.Twin screw extruder
2.baby food, FBF, etc
3.Capacity: 150kg/h, 240kg/h,500kg/h
nutritional baby rice flour machine
Description:
Baby food machinery is used to produce infant baby food and some other instant flour products. The raw material is put in the mixer then mixed ingredients are fed into extruder feeder. The extruder is fitted with: special cylindrical holding silo; vibratory doser with hopper to feed the extruding screw; extrusion mechanism and cutting; independent electric panel.
After the extrusion the product is conveyed till the continuous rotary drier through a pneumatic conveyor. The continuous rotary drier has a heat exchanger with gas burner that allows a better heating of the product and it is economically viable owing the low cost of electric power. Case the client prefers we have the electric drier also.
Raw materials: adopts cereals flour (corn, wheat, rice, oat, soy, etc)
Products: baby food, FBF, CSB and samaposha etc
Capacity: 150kg/h, 240kg/h, 500kg/h
Flow chart: Mixing system---Extrusion system---- -Drying system----Milling system---Packing system
Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries
Machines Materials: All the machines are made by stainless steel
Technical Parameters
Model |
Installed power |
Real power |
Output |
Dimension |
ZH65 |
66kw |
50kw |
100-150kg/h |
19000x1200x2200mm |
ZH70 |
100kw |
67kw |
200-240kg/h |
21000x1500x2200mm |
ZH85 |
130kw |
80kw |
400-500kg/h |
30000x3500x4300mm |
Our services
(1). Free consultation service before, during, and after sales;
(2). Free project planning and design services;
(3). Free debugging of equipment until everything is functional;
(4). Free training of equipment maintenance and operating personally;
(5). Free new production techniques and formulas;
(6). Provide 1 year complete warrantee and lifetime maintenance service.
Production Advantage:
1. The motor of our extruder machine is Siemens Motor.
2. The raw material of our machines is Stainless Steel.
3. Our automatic machines are controled by frequency changer, it is easy to operate.
4. Our factory will send our engineer to install machines for you.
5. baked snack machine have the 12 months guarantee time.
6. The machine is multifunction. Many types of snacks can be manufactured by changing the die head and model.
Company Introduction:
Jinan Zhuoheng Extrusion Machinery Co., Ltd., a shareholders-owned and operated business established more than 10 years ago, is considered as one of Chinese most respected and experienced suppliers of snack food equipment, accessories and services.
Zhuoheng has a comprehensive manufacturing program offering equipment and systems to
customers in extruded snack food processing machinery and allied industries. We can supply
individual items of equipment or complete factory layouts and lines, which are custom-built to meet the requirements of customers. Our spare part and service division demonstrates our continuous commitment to customers' support and after-sales service. We have successfully completed several large-scale projects from planning to completion and project management. Zhuoheng has a proven record of quality and service
Delivery
The machines is possible to pack in wooden case or nude pack after wraping by plastic film
Sample pictures
baby flour production line ; baby rice powder machine ; instant baby poweder food macine
