Specifications
Timber Wood Trailer with Crane(grapple)Attachments Easy-Exchange
Hydraulic system to use independent diesel engine
Log Trailer with Crane |
5T |
Model |
ZM5004 |
Matching Power |
30-60 hp |
Machine Weight (kg) |
2040 |
Referenced Packing Dimensions/unit(mm) |
4500×1500×1050 |
1.Trailer Section | |
Trailer Model |
TR50 |
N/W of Trailer(Kg) |
940 |
Rated Loading Capacity |
5T |
Loading Area |
1.6m2 |
Total Length of Trailer |
5.1m |
Trailer Loading Length |
3.1 m |
Total Width of Trailer |
1.8 m |
Dimensions of Trailer Frame |
140x140x6 mm |
Assistant Hydraulic Steering |
Yes |
Dia.of Traction Hole |
38 mm |
Tire Model |
8.25-16 |
No. of Tires |
4 |
Referenced Packing Dimensions/unit(mm) |
4350×1390×750 |
2:Hydraulic Crane Section | |
Model |
CR04 |
Weight of Crane (Kg) |
1100 |
Max. Arm Reach |
4.3m |
Lifting Capacity/Arm Reach(kg/m) |
1280/2,760/3,500/4,450/4.3 |
Rotating Angle |
400° |
Max.Grab Opening Width(mm) |
1300 |
Grabbing Dia.of Logs(mm) |
70~485 |
Rotator Load-bearing Capacity(Kg) |
3000 |
Referenced Packing Dimensions/unit(mm) |
2800×1300×550 |
FEATURE
1. Matching Tractors, ATV or truck
2. PTO, Gas/Diesel engine
3. Air Brake and wide tyre available
4. Hydraulic Transmission in Compact structure
5. Flexibility and convenient operation
6. Quick mounting and dismounting
THE MACHINE DISPLAY
DETAILS DISPLAY
