Articulated Tractor 904 Made in China

Articulated Tractor 904 Made in China thumbnail-1
Articulated Tractor 904 Made in China photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Weifang Fumei Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 66.2kw
Certificate CE
Brand Name FM or OEM as required
Model Number TY904
Place of Origin Shandong, China
After-sales Service Provided Engineers available to service machinery overseas

Specifications

High quality 90hp 4wd tractor
1)YTO LR4M5-23 engine
2)Tire size(front/rear)12.4-24/16.9-34
3)PTO speed:760/1000 r/min

Model

704

804

904

Type

4WD Wheeled Type

4WD Wheeled Type

4WD Wheeled Type

Length(to the front ballast)

4052mm

4090mm

4530mm

Width

1900mm

1900mm

2050mm

Height (to the exhaust vent)

2690mm

2690mm

2810mm

Front Wheel Tread

1455mm

1455mm

1600mm

Rear Wheel Tread

1510mm

1520mm

1608mm

Axle Base

2278mm

2316mm

2210mm

Min. Ground Clearance

350mm

350mm

405mm

Structure weight

2940kgs

3010kg

3300kg

Rated traction force

1480kgs

1520kg

1600kg

Engine Model

4108

4108

4MC-T68X

Engine Type

4-Cylinder

4-Cylinder

4-Cylinder

Cooler type

Water

Water

Water

Stroke

4 Stroke

4 Stroke

4 Stroke

Rated Power

51.4kw

58.8kw

66.2kw

Rated Speed

2200r/min

2200r/min

2300r/min

Fuel

Diesel

Diesel

Diesel

Front Wheel Tyre

8.3-24

8.3-24

12.4-24

Rear Wheel Tyre

14.9-30

14.9-30

16.9-34

Clutch

Dual-stage clutch

Dual-stage clutch

Dual-stage clutch

Steering

Power steering

Power steering

Power steering

Suspension Type

3-point links

3-point links

3-point links

PTO

With dual speed PTO

With dual speed PTO

With dual speed PTO



Advantages and Characteristics of 80 series tractors:
1. Equipped with famous brand engine showing advanced capacity, low fuel consumption and high economic efficiency.
2. Reasonable distribution of speed, high efficiency in both farm working and transportation.
3. 150L enlarge fuel tank, long working time.
4. Double cylinder strong take-up device, with height limit, strong lift force, reliable and high efficiency.
5. Installed famous brand clutch, optional Germany LUK brand clutch.
 6. Optional to install 16F/8R creeper shift or 8F/8R shuttle shift, the shifts matched reasonable, have a good agricultural adaptability.
7. Optional double speed PTO( Power Take Off): 540/1000,760/1000r/min showing high working effiency.
 8. Optional PTO shaft of 6 spline or 8 spline, adaptable for agricultural equipment of all over the world.
9. Stremlined appearance design, beautiful and generous.
10. Optional luxury closed drivers cabin, equipped air-conditioner, CD player, radio, adjustable soft seat, luxury inner decorations etc..
articulated tractor 904 made in china

Tractor of this kind
articulated tractor 904 made in chinaarticulated tractor 904 made in china
articulated tractor 904 made in china
articulated tractor 904 made in china
articulated tractor 904 made in china
